36
Wired Controller Wiring Instruction
Communication wiring
Communication wiring length (m/ft) Dimensions of wiring
< 100m/328ft
0.3mm
2
x3-core shielded
wire (22AWG,3wire)
≥100m/328ft and <200m/656ft
0.5mm
2
x3-core shielded
wire (20AWG,3wire)
≥200m/656ft and <300m/984ft
0.75mm
2
x3-core shielded
wire (18AWG,3wire)
Note:
• One side of the shielded sheet of communication wire must
be earthed.
• The total length of communication wire cannot exceed 300
meters.
