23
10
Attaching the
diagonal stays
First assemble four ladder
rungs with threaded rods
and guide stops.
Equip four diagonal stays
with end caps.
Attach the diagonal stays
in the position shown using
wing-nuts (inserting an
additional U-shaped washer
on the opposite side to the
stay).
Dismantling the scaffold
The aluminium ladder
scaffolding is dismantled in
the reverse sequence to
erection.
GB
