Halfen HSC - Product Identification; Stud Head Details; Sleeve and Bar Identification; Bar Diameter and Thread Specifications

2
© 2017 HALFEN · INST_HSC 10/17 · www.halfen.com
HALFEN HSC Assembly instructions
Deutsch EnglishFrançaisPolski
H
D
□ 75 mm
h = 9 mm
H
D
HSC
20
S∅20
xyy
Concreting
step 2
Concreting
step 2
Concreting
step 1
Monolithic solution
Magnetic plate Nailing plate, metalNailing plate, plastic
The thread of the HSC Socket bars must
be covered and protected with a sealing
cap.
Stud heads Sleeves
HSC-S, HSC-SD
Single headed,
female bar
Single headed,
male bar
Double female bar Double headed bar Single headed bar
HSC-S HSC-A HSC-SD HSC-HD HSC-H
Manufacturer’s mark
Product,
bar diameter d
HSC
Formwork accessories
Installation examples
Product overview
Identifi cation
HSC-HD
Multi-phase concreting solutions
HSC-A
HSC-A
HSC-SD
Nailing plate
Variant 2: simplifi ed
key joint
Variant 1: Interlocking joint in accor-
dance with DIN EN 1992-1-1


Pos

: Construction bar for stirrups
Female and male bars
Bar diameter d
s
12 16 20 25
Thread
M12 x 1.75 * M16 x 2 * M20 x 2,5 * M25 x 2,5
Colour;
protection plug
green orange light blue brown
* = ISO standard metric screw thread (DIN 13-1)
12 - 16 - 20 - 25
