SAFETY
SAFETY WARNINGS AND CAUTIONS
Ensure all below instructions and the main cabinet instructions are
followed.
• These side extensions are only designed to fit to the Halfords base
cabinets.
• This product must be fitted according to the below instructions using
the fixing kit provided.
• Do not attempt to lift the main cabinet by the side extensions.
• Do not open more than one drawer at a time, this weight transfer could
cause the unit to fall towards the user.
• When loading the drawers, place heavier items at the bottom of the unit.
• Ensure the main cabinet is loaded with tools before loading the side
cabinets. Failure to do this will cause the cabinet to become unstable.
• Do not stand on the box or in/on the drawers.
• Not suitable for mounting on a truck bed or any other moving objects.
• Keep this product on level surfaces. The unit may become unstable
and tip if stored or moved on an un-even surface.
• Do not exceed the stated maximum weights listed below.
2
Drawer Dimension:
Row 1 to 2: 2xW=263.5mm H=72.4mm D=387.9mm
Row 4: W=263.5mm H=215.4mm D=387.9mm
Row 3: W=263.5mm H=151.4mm D=387.9mm
Maximum Weight per Small Drawer (x2): 10KG
Maximum Weight per Big Drawer (x2): 20KG
650mm
456mm
356mm
356mm
650mm
456mm
356mm
356mm
Maximum Weight for Top Compartment: 15KG
Maximum Weight for Bottom Compartment: 25KG
Compartment Dimension:
Top: W=293.5mm H=146mm D=424.2mm
Bottom: W=293.5mm H=348mm D=424.2mm
Product Specifications
