HALLDE • User Instructions
6
the cutting tool clockwise to release it.
FAULT: The agitator device, locking bolt or
decoring device cannot be removed.
REMEDY: Use the wrench to unscrew it clock -
wise.
TECHNICAL SPECIFICATION
HALLDE RG
-
300i
MACHINE: Motor: One speed, 0.75 kW,
380-415 V, 3-phase, 50-60 Hz, with thermal
motor protection. Transmission: gear. Safety
system: Three safety switches. Degree of
protection: IP44, buttons IP65. Power supply
socket: Earthed, 3-phase, 16 A. Fuse in fuse
box for the premises: 10 A, delayed. Sound
level LpA (EN31201): 70 dBA.
TOOLS: Diameter: 215 mm. Speed: 400 rpm.
NET WEIGHTS: Machine: 37 kg. Feed cylinder:
6 kg. Feed hopper with cylinder: 11 kg.
Manual push feed attachment: 5.8 kg. 4 tube
insert: 5 kg. Cutting tools: About 1 kg on
average.
NORMS/STANDARDS: See declaration of
conformity.
