Hamilton Beach 40715 - Parts and Features; Component Identification

4
1 2
Parts and Features
To order parts, visit:
hamiltonbeach.com/parts
1 Espresso/Pod Filter Holder
2 Espresso Filter Holder
3 Ground Espresso/Pod Filter Holder
4 Removable Cup Rest
5 Removable Drip Tray
6 Lid
7 Brew Head
8 Frothing Nozzle and Cover
9 Water Reservoir Lid
10 Removable Water Reservoir
11 Measuring Scoop
11a Frothing Nozzle Wrench
11b Tamping Tool
12 ON/OFF Indicator Light
13 Ready Indicator Light
14 Start Button Light
15 ON/OFF Button
16 Steam/Espresso Button
17 Start Button (begins dispensing)
18 Steam Control Dial
11
11a
11b
3
4
5
7
6
8
9
10
15
16
17
18
12
13
14
