Place the pulp container into position
by tilting the container slightly.
Place a glass or other container
under the juice spout.
6
Slide the food pusher down the feed
chute by aligning the groove in the
food pusher with the small ridge on
the inside of the top of the feed tube.
8
6
7
Hint!
To minimize cleanup, place a plastic
grocery bag in the pulp container to
collect the pulp. (See page 7 for more
information.)
Small Ridge
Inside Feed
Chute
How to Assemble (cont.)
Raise the locking latches up to lock
into place.
5
