Hamilton Beach 67601 - How to Disassemble; Disassembly Procedure

8
Turn juice extractor OFF and
unplug. Allow strainer basket to
stop turning.
How to Disassemble
Remove the pulp container by sliding
away from motor base.
Release locking latches.
Move the locking latches down.
Lift off the strainer bowl with the
strainer basket still in place.
1
5
2
3
Lift off the cover.
4
6
7
To remove the strainer basket, turn
the strainer bowl upside down and
carefully remove the strainer basket.
(It is recommended to remove the
strainer basket over a sink.)
