Parts and Features
To order parts, visit:
hamiltonbeach.com/parts
Before first use: Wash all removable parts in
hot, soapy water. Rinse and dry. Brew one
cycle with water and discard water.
1 Lid Latch
2
Gray Removable Single-Serve
Pack Holder with Handle
3
Brown Removable Brew
Basket for Ground Coffee with
Hinged Lid and Handle
4
Removable Cup Rest with
Drip Tray
5 Lid
6
Gray Removable Needle
Holder with Black Seal
7 Water Reservoir with Lid
8 Water Window
9 Funnel
10 Control Panel
11 BOLD Button
12
HEATING or Icon
13 REG Button
14 Travel Cup Rest
6
7
8
10
14
9
10
11
12
13
4
3
2
1
