Hamilton Beach REFHB17B - Reversing the Door

Refrigerator REFHB17W/REFHB17B Use and Care Manual Support: 1-877-395-5109
9
REVERSING THE DOOR
1. Top hinge cover
2. Top hinge screw
3. Top hinge
4. Cabinet plug
5. Bottom hinge
6. Door handle plug
7. Bottom hinge screw
8. Leveling leg
Do not tilt the appliance over
45°when revising the door as
possible damage to the sealed
system may occur.
1. Remove top hinge cover and 3 top hinge screws which are below it. Then
remove top hinge.
2. Remove 1 cabinet plugs and 1 door handle plug.
3. Remove the door.
4. Remove right and left leveling legs.
5. Remove the bottom hinge and 3 bottom hinge screws.
6. Install the bottom hinge on the other side of the leveling legs with 3
bottom hinge screws.
7. Install right and left leveling legs. There are two holes below the
refrigerator to fit the two leveling legs.
8. Install the door.
9. Install the top hinge on the other side with 3 top hinge screws.
10. Install top cover above the top hinge and install 1 cabinet plugs and 1
door handle plug on the other side.
11. Adjust the leveling legs.
