Hamilton C2000 - Switch Settings (3 Hopper Mode)

Document #101-0009 13 3/09/05
Switch Settings
3 Hopper Mode
SWITCH SETTING MODE OF OPERATION/PAYOUTOPTIONS
OFF + + + + + + + + + + +
ON +
2 A B C D E F G H I J K L
OFF + + + + + + + + + +
ON + +
3 A B C D E F G H I J K L
OFF + + + + + + + + + +
ON + +
6 A B C D E F G H I J K L
OFF + + + + + + + + +
ON + + +
35 A B C D E F G H I J K L
OFF + + + + + + + + +
ON + + +
74 A B C D E F G H I J K L
OFF + + + + + + + + + +
ON + +
80 A B C D E F G H I J K L
OFF + + + + + + + + +
ON + + +
98 A B C D E F G H I J K L
OFF + + + + + + +
ON + + + + +
158 A B C D E F G H I J K L
3 HOPPERS - QUARTERS, DIMES, NICKELS
1$ = 3q+2d+1n 10$ = 38q+4d+2n
5$ = 19q+2d+1n 20$ = 76q+8d+4n
3 HOPPERS - QUARTERS, DIMES, NICKELS
1$ = 3q+1d+3n 10$ = 38q+2d+6n
5$ = 19q+1d+3n 20$ = 76q+4d+12n
3 HOPPERS - QUARTERS, DIMES, NICKELS
1$ = 2q+4d+2n 10$ = 36q+8d+4n
5$ = 18q+4d+2n 20$ = 72q+16d+8n
3 HOPPERS - QUARTERS, QUARTERS, QUARTERS
1$ = 4q 10$ = 40q
5$ = 20q 20$ = 80q
3 HOPPERS -QUARTERS, DIMES, NICKELS
1$ = 4q 10$ = 40q
5$ = 20q 20$ = 80q
3 HOPPERS -TOKENS, TOKENS, TOKENS
1q = 1t 10$ = 40t
1$ = 4t 20$ = 80t
5$ = 20t
3 HOPPERS - QUARTERS, DIMES, NICKELS
1n = 2d+1n 10$ = 39q+2d+1n
1$ = 3q+2d+1n 20$ = 79q+2d+1n
5$ = 19q+2d+1n
3 HOPPERS - TOKENS, TOKENS, TOKENS
1$ = 4t 10$ = 40t
5$ = 20t 20$ = 100t
