OPERATION
24 © HAMM AG 2009
2 OPERATION
2.1 CONTROL AND
OPERATION ELEMENTS
2.1.1 General
These operating instructions apply to several
types of this series. Therefore it is possible that
these instructions include descriptions of oper-
ation elements not installed in your machine.
The position numbers refer to the description
of the individual elements in this chapter. In the
text for operation and maintenance, these po-
sition numbers are in brackets.
2.1.2 Overview
302 EMERGENCY STOP switch
(NOT-STOP)
501 Driving lever
503 Multifunctional grip
Vibrator OFF-ON
504 Engine speed
10082-10
302 503
501
504
