Hammer Strength HDADJ - Components List

6
COMPONENTS LIST *
HARDWARE:
ITEM NO. QTY. PART NO. DESCRIPTION
1 1 7354001 Back Pad
2 1 HDADJ-CSB-0 Back Pad Bracket
3 6 3251703 M10 x 30mm Screw
4 6 WASH.375SAE 3/8” SAE Washer
5 1 HDADJ-BF-0 Base Frame
6 3 HDADJ PIN Seat Pin
7 1 7351901 Seat Pad
8 1 HDADJ-21-00 Seat Pad Bracket
9 1 WARNING LARGE-H Large Horizontal Warning
10 2 8039500 Pinch Label
REQUIRED TOOLS
RATCHET with 17mm SOCKET
3
M10 x 30mm Screw
4
3/8” Flat Washer
6
Seat Pin
* Contact Customer Service at (800) 351-3737 or (847) 451-0036 for a detailed parts list.
