KEY REST
J501 1 AES15-4 YEL SW AES-15 +5V 2 -9 RED CS
2 J201-3 CTH-31A +5V 3 -11 ORG RD
3 J18-1 VGH-40B +5V 4 -10 YEL KEY IREQ
4 NC 5 -1 GRN D0
5 AES15-2 BLK SW AES-15 DGND 6 -2 BLU D1
6 J201-5 CTH-31A DGND 7 -3 VIO D2
7 J18-6 VGH-40B DGND 8 -4 GRY D3
J502 1 NC +5V 9 -5 WHT D4
2 J301-1 BRN SWH-481C SW IN 10 -6 PNK D5
3 -2 RED SW OUT 11 -7 BRN D6
4 NC DTR 12 -8 RED D7
5 NC VAS VIN1 13 NC
6 -3 ORG SW RES J510 1 NC +5V
7 -6 BLK DG 2 J604-3 BRN EFH-236A OUT
J503 1 BREAK SW-2 YEL BREAK SW +5V 3 -2 RED IN
2 J1002-3 YEL SWH-487A +5V 4 -4 ORG DSP RES
3 BREAK SW-1 ORG BREAK SW CPU AN2 5 -1 YEL KEY DOWN
4 BREAK SW-3 BLK BREAK SW PICH 6 -6 BLK DG
5 J1002-1 BRN SWH-487A MOD J513 1 J905-3 BRN VGH-39A LSV0
6 -2 RED AIN4 2 J905-4 RED RSV0
7 -4 ORG AIN5 3 J905-5 ORG LSV1
8 -5 YEL AIN6 4 J905-6 YEL RSV1
9 -6 BLK DGND 5 J905-2 GRN LSV2
J504 1 J15-1 BRN VGH-40B BAS IN 6 J905-1 BLU RSV2
2 -2 RED BAS OUT 7 NC
3 -3 ORG BAS RES 8 NC
J506 1 BLK DGND 9 J903-4 VIO WDCLK
2 YEL LCD+5V 10 J903-6 GRY BCLK
3 CN2-2 BRN LCD UNIT CONT 11 J906-2 WHT SELA2
4 CN1-6 RED LCDA0 12 J906-1 PNK SELB2
5 CN2-3 ORG LCDR/W 13 J906-3 BRN ENB
6 CN1-5 YEL LCDE 14 NC DG
7 CN2-4 GRN D0 15 J904-1 RED LSV3
8 CN1-4 BLU D1 16 J904-2 ORG RSV3
9 CN2-5 VIO D2 17 J904-4 YEL LSV4
10 CN1-3 GRY D3 18 J904-3 GRN RSV4
11 CN2-6 WHT D4 19 J903-1 BLU LSV5
12 CN1-2 PNK D5 20 J903-2 VIO RSV5
13 CN2-7 BRN D6 J514 1 J905-3 BRN VGH-39A LSVI0
14 CN1-1 RED D7 2 -4 RED RSV0
15 CN2-1 BLK DG 3 -5 ORG LSV1
16 CN1-7 YEL +5V 4 -6 YEL RSV1
J507 1 J701-3 YEL IFH-13B +5V 5 -2 GRN LSV2
2 -1 BRN MIDI IN 6 -1 BLU RSV2
3 -2 RED MIDI OUT 7 NC DG
4 NC SW RES 8 NC DG
5 -4 BLK DG 9 J903-4 VIO WDCLK
J508 1 J402-4 WHT TGH-53A ST1 10 J903-6 GRY BCLK
2 -3 PNK ST2 11 J906-2 WHT SELA2
3 -19 BRN D0 12 J906-1 PNK SELAB2
4 -17 RED D1 13 J906-3 BRN ENB
5 -15 ORG D2 14 NC DG
6 -13 YEL D3 15 J904-1 RED LSV3
7 -11 GRN D4 16 J904-2 ORG RSV4
8 -9 BLU D5 17 J904-4 YEL LSV4
To Next Page
