Hammond XK-1 Service Manual

8-4
XK-1
3.ENDBLOCK L ASS'Y(66710-02102)
Endblock Bracket L2
1
2
5
3
4
6
00452-40203
66710-02105
00443-01348
66710-02107
00451-40554
00451-40555
Drawbar Ass'y DB-609A
7
00278-51001
SWH-510A Ass'y
Keytop #1
1
2
00225-42236
00452-40205
Keytop #2-K
3
00452-40206
Endblock L
Switch Board EL Ass'y
WR-HZ133-C
Wheel Ass'y
Endblock Bracket L1
00683-54012
00683-53006
Cross Recessed Tapping Screw
(For Plastic)(Binding Head, 4x12, ZnB)
Cross Recessed Tapping Screw
(For Plastic)(Binding Head, 3x6, ZnB)
00655-53025
8
Cross Recessed Tapping Screw Type2
(Fluted Point)(Binding Head, 3x25, ZnY)
9
10
2
3
4
10
6
7
8
9
5
10
9
1
10
3
3
2
1
4.SWITCH BOARD L ASS'Y(66710-02103)
