XK-1
8-5
5.SWITCH BOARD R ASS'Y(66710-02104)
6.SWITCH BOARD EL ASS'Y(66710-0215)
1
2
00225-42246
00452-40205
SWH-512A Ass'y
Keytop #1
1
2
3
00225-42241
00452-40206
00452-40207
SWH-511A Ass'y
Keytop #2-K
Keytop #2-R
7.BOTTOM PANEL ASS'Y(66710-02201)
1
2
00451-40550
00453-40028
Bottom Panel
Plastic Foot
8.SIDE BOARD L ASS'Y(66710-02202)
1
2
00452-40203
66710-02105
Side Bracket L
Side Board L
3
66710-02105Cross Recessed Tapping Screw Type1
(Truss Head, 4x16, ZnY)
1
2
3
1
1
2
1
2
2
2
2
3
2
