4
NAMES AND FUNCTIONS
❶ Pedal Keyboard
20-note non-velocity pedal keyboard.
❷ Expression Bracket 1
is bracket is a base for mounting the optional Expression
Pedal EXP-100F, EXP-50, EXP-20 or V-20R.
❸ LED
is LED dimly lights when the power is ON. It also indicates
the playing status of the pedal keyboard (lights up when be-
ing played) and the MIDI channel.
❹ Cord Hook
Hook the AC Adaptor Cord or the DCC-2 Cable on this to
provide a strain relief.
❺ DC IN Jack
is jack connects the attached AC Adaptor AD1-1508 (or
AD3-1508) or DCC-2 Cable.
❻ MIDI IN 1 Jack
is is a MIDI input Jack. MIDI signals received at this input
will be merged with the playing information of the Pedal-
board and sent out the MIDI OUT jack.
❼ MIDI IN 2 Jack
is is also a MIDI input Jack. MIDI signals received at this
input will be merged with the playing information from
MIDI IN 1 and the playing information of the Pedalboard
and sent out the MIDI OUT jack.
❽ MIDI OUT Jack
is jack sends out the playing information of the Pedalboard
as well as any merged informaition from MIDI IN 1 or 2.
❾ M4 x 5 Screw (2)
Use these screws for attaching the Expression Pedal EXP-
100F or EXP-50 to Expression Bracket 1.
❿ ø4 x 8 Screw (2)
Use these screws for attaching the Bracket Spacer.
⓫ Bracket Spacer
⓬ Expression Bracket 2
ese (⓫ and ⓬) are used together with the Expression
Bracket 1 for attaching the Expression Pedal EXP-20 or V-
20R.
❷
❸
❶
❹❺ ❻ ❼ ❽
❾❿ ⓫ ⓬
