USER MANUAL | 25
EN
D.2
D.1
D.3
A
D.4
EMERGENCY OPERATION >SLIDE TRACK
[D.1]Your Slide Track is fitted with a manual override that allows the track to be
moved in case of an emergency. This is positioned towards the bottom of the
track{A}. [D.2]Turn off the lift. [D.3]To move the Slide Track manually you must
first loosen the locking bolt. [D.4]Use the spanner supplied as shown in
(Figure D.4) to move the Slide Track.
