17" LCD Color Monitor Hanns.G AG172D
19
5.2 Electric Block Diagram
LCD interface
(CN101)
Scalar TSUM56AK
(Include ADC, OSD)
(U401)
D-Sub
Connector
(CN405)
H sync
V sync
RGB
Crystal (14.318MHz)
(X401)
EEPROM
M24C02-WMN6TP
(U404)
EEPROM
PM25LV010-25
(U402)
DVI
Connector
(CN406)
Digital
Video
Signal
EEPROM
M24C02-WMN6TP
(U405)
