Hans Grohe Raindance E - Safety Notes; General Safety Warnings; Installation Instructions; Installation Guidelines and Wall Requirements

4
> 50 l/min
Quattro
Trio
Raindrain
X
Centershowertub
English
Safety Notes
Glovesshouldbewornduringinstallationtoprevent
crushingandcuttinginjuries.
Theshowersystemmayonlybeusedforbathing,
hygienicandbodycleansingpurposes.
Childrenaswellasadultswithphysical,mental
and/orsensoricimpairmentsmustnotusethis
showersystemwithoutpropersupervision.Persons
undertheinuenceofalcoholordrugsareprohibi
-
tedfromusingthisshowersystem.
Donotallowthestreamsoftheshowertouchsen
-
sitivebodyparts(suchasyoureyes).Anadequate
distancemustbekeptbetweentheshowerandyou.
Thearmoftheshowerheadisintendedonlytohold
theshowerhead.Donotloaditdownwithother
objects!
Installation Instructions
Thettingmustbeinstalled,ushedandtestedafter
thevalidnorms!
Wherethecontractormountstheproduct,heshould
ensurethattheentireareaofthewalltowhichthe
mountingplateistobetted,isat(noprojecting
jointsortilesstickingout),thatthestructureofthewall
issuitablefortheinstallationoftheproductandhas
noweakpoints.Theenclosedscrewsanddowelsare
onlysuitableforconcrete.Foranotherwallconstruc
-
tionsthemanufacturer’sindicationsofthedowel
manufacturerhavetobetakenintoaccount.
Thismixercannotbeusedinconjunctionwith
hydraulically,electronicallyorthermallycontrolled
instantaneousheaters.
Technical Data
Operatingpressure: max.0,6MPa
Recommendedoperatingpressure: 0,1–0,4MPa
(1MPa=10bar=147PSI)
Hotwatertemperature: max.60°C






•
•
•
Assembly see page 31
Warmwater
Coldwater
Donotusesiliconecontainingaceticacid!
Thewallmustbereinforcedinthisarea.
Shutovalve
Quattro4-WayDiverterValve
Trio 2-Way Diverter Valve with integrated
Shut-ovalve
Plugtheunusedoutlet.
Thewastedrainperformancemustbemore
than50l/min.
Waste
Dimensions (seepage31)
Flow diagram (seepage33+35)
Spare parts (seepage38)
Cleaning (seepage39)
