Hansen HA4AS User Manual

OIL CAPACITIES (U.S. GPM)
APPLICATION: SCREW COMPRESSOR OIL PUMP
RELIEF REGULATOR (HA4AL)
LIQUID CAPACITIES (U.S. GPM)
APPLICATION: REFRIGERANT PUMP RELIEF
REGULATOR (HA4AL)
Capacities assume no gas flashing. No capacity correction
required for temperatures between –40°F (–40°C) and +40°F
(+4.4°C).
Capacities based on oil with less than 300SSU viscosity.
† Bypass from intermediate pressure at saturation temperature to booster suction.
*These capacities are not for hot gas defrost relief. See the chart in the middle of this page.
**Optional 25% and 50% reduced capacity ¾" (20mm) plugs are available.
Discharge gas capacities are based on +15°F (+10°C) evaporator temperature.
*Or an outlet pressure regulator with electric shut-off (HA4AOS).
Evaporator tons at 10°F (5.6°C) TD (temperature differential), valve capacities are conservative. These capacities can be
modified up or down depending on type of evaporator, temperature, mass, frost thickness, defrosting time, etc. Typical
for –20°F (–28.9°C) evaporator.
HOT GAS DEFROST NOMINAL VALVE SIZING CAPACITIES
(DEFROSTING EVAPORATOR SIZE TONS)
GAS CAPACITIES (TONS)*
(1 Ton=12,000 Btu/hr=3.517 kW=3042 kcal/hr)
PORT SIZE
(mm)
R717
ΔP=30 psi
(2 bar g)
R22
ΔP=30 psi
(2 bar g)
¾" (20)
45 30
1" (25)
82 56
1¼" (32)
114 78
1½" (40)
256 168
2" (50)
324 230
2½" (65)
553 377
3" (80)
733 505
PORT SIZE
(mm)
OIL
ΔP=30 psi
(2 bar g)
¾" (20)
48
1" (25)
87
1¼" (32)
122
1½" (40)
260
2" (50)
350
2½" (65)
574
3" (80)
775
REFRIG. APPLICATION
PORT SIZE (mm)
¾" (20) 1" (25) 1¼" (32) 1½" (40) 2" (50) 2½" (65)
R717
Hot Gas Solenoid* 9 to 15 15 to 28 28 to 39 39 to 73 73 to 106 106 to 165
Defrost Relief
Regulator
17 to 24 24 to 45 45 to 60 60 to 96 96 to 140 140 to 225
R22
Hot Gas Solenoid* 6 to 8 8 to 15 15 to 20 20 to 32 32 to 47 47 to 75
Defrost Relief
Regulator
6 to 8 8 to 15 15 to 20 20 to 32 32 to 47 47 to 75
SIZE
(mm)
DISCHARGE GAS REGULATOR HOT GAS BY-PASS TO SUCTION
R717 R22 R717 R22
+86ºF (+30ºC)
CONDENSING
+140ºF (+60ºC)
DISCHARGE
+86ºF (+30ºC)
CONDENSING
+140ºF (+60ºC)
DISCHARGE
+86ºF (+30ºC)
CONDENSING
+140ºF (+60ºC)
DISCHARGE
+15º F ( – 9.4ºC)
CONDENSING
+15º F ( – 9.4ºC)
DISCHARGE †
+86ºF (+30ºC)
CONDENSING
+140ºF (+60ºC)
DISCHARGE
+15º F ( – 9.4ºC)
CONDENSING
+15º F ( – 9.4ºC)
DISCHARGE †
2 psid 5 psid 2 psid 5 psid
¾" ** (20) 17 27 6.1 9.5 88 27 32 12
1" (25) 31 49 11 17 160 49 58 22
1¼" (32) 44 69 16 24 224 68 81 31
1½" (40) 94 147 33 52 479 146 173 66
2" (50) 126 197 45 70 643 196 232 89
2½" (65) 206 323 73 115 1054 321 380 146
3" (80) 279 437 99 155 1424 434 513 197
4" (100) 445 698 158 241
Hot gas bypass capacities are based on above given temperatures. Liquid
temperature is the same as condensing temperature. Evaporator temperature
+40°F (+4.4°C) or less for +86°F (+30°C) condensing; –22°F (–30°C) evaporator
for +15°F (–9.4°C) condensing.
5" (125) 649 1017 230 361
6" (150) 1108 1735 393 616
5
R429d
AUG 2015
