Hantech 10474164 - Page 6

– 6 –
Component
Exhaust Pipe Assembly
Window Sealing
Plate Assembly
9
10
12
11
13
14
1
3
4
5
8
7
2
1 Top cover 8 Base plate
2
Control panel
9
EVA Filter
3 Hand 10 Continuous Drainage Hole
4 Air outlet Lourcer 11 Wrapping Post
5 Front Housing 12 Air Vent
6 Rear Housing 13 CON Filter
7 Caster 14 Drainage Hole
6
