Performance indicators
EN
HDP10000 series user manual Copyright Qingdao Hantek Electronics Co., LTD
16
Current
Overcurrent protection
(OCP)
HDP135V6S
0 ~ 7A ± 0.2%FS
HDP180V8S
0 ~ 8.8A ± 0.2%FS
HDP1160V4S
0 ~ 4.4A ± 0.2%FS
Maximum current
HDP135V6S
6.2A ± 0.2%
HDP180V8S
8.2A ± 0.2%
HDP1160V4S
4.1A ± 0.2%
Quick charge
Output voltage range
5V ~ 12V
Output power
Maximum 18 W
Supported quick charging
protocol
DCP (Apple, Samsung and BC1.2), Qualcomm
QC2.0/QC3.0, Huawei Quick Charge Protocol FCP,
Samsung Quick Charge Protocol AFC
General features
Remote interface
RS232 (Female connector)
Baud rate: 2400
Data bit: 8
Stop bit: 1
None Parity check
AC input
115 Vac ± 10%, 230 Vac ± 10%, 50/60Hz
Working conditions
Temperature -10 ° C to 40 ° C, relative humidity ≤80%
Storage conditions
Temperature -20 ° C to 60 ° C, relative humidity ≤80%
Cooling
Air cooling
Weight
HDP135V6S
1.3Kg
HDP180V8S
1.5Kg
HDP1160V4S
1.5Kg
Dimensions
85×160×260(mm)
Table 6.1 Indicators
