EN
17
• Use a rubber mallet to avoid damaging the material.
• Place the unit on a level surface. Otherwise this will compromise safety, or the maximum
supporting capacity.
• Only use plugs and screws suitable for the type of wall and weight of the shelves. Plugs,
screws and tools for wall mounting sold separately.
PARTS
7
9
x5
x3 8 x2
10 x6 11 x4
1 x6
x10
x10
x4
x5
x5
2
3
4
5
6
