SSTTEEEERRIINNGG CCOOLLUUMMNN WWIITTHH CCOONNSSOOLLEE
22-55 CCOONNSSOOLLEE DDEESSCCRRIIPPTTIIOONN
22-44 CCAABB AACCCCEESSSS
Battery charge warning lamp
Engine oil pressure warning lamp
Parking Brake Light
Direction indicator warning lamp
Position lamp and dipped beam control
lamp
Head lamp, main beam
Rev. counter and hour meter
Hazard warning light switch
Multi-function control switch
Horn
Pre Heating light
Fuel gauge
Rotating amber warning beacon swit-
ch
Engine temperature gauge
Engine temperature and coolant
gauge light
When the machine is stopped, the ladder is at low position.
- To raise automatically the ladder, start the engine
AANNDD
release the parking brake .
- To come down the ladder, stop the engine
OORR
operate the parking brake.
OR
