HARDI-EVRARD ALPHA PLUS 4100 - Page 41

ALPHA PLUS HARDI NOVA
PP RR EE PP AA RR AA TT II OO NN
CHAPTER
33-
2
90
110
130
150
170
190
210100
90
80
70
60
50
40
30
U C C
MAXI
MINI
33-44 SSCCRREEEENN WWAASSHH RREESSEERRVVOOIIRR
- Fill the screen wash reservoir with liquid for screen wash
- Check the hydraulic oil level through a sight glass situated on the left-
hand side of the oil reservoir. A thermometer indicates the oil tempera-
ture.
This
6600
litre reservoir is located under the cab. The filler cap is
situated on the reservoir on the left-hand side of the machine
((11))
- Carefully clean the tank cap.
- Do not let any impurities in; use a funnel if necessary.
- Take care do not let any water in the oil tank
- Always fill the reservoir with hydraulic oil of the same characteris-
tic as those of previous oil. (
TTOOTTAALL EEQQUUIIVVIISS ZZSS4466
).
Sight-glass and température
33 -33 HH YY DD RR AA UU LL II CC OO II LL RR EE SS EE RR VV OO II RR
