ALPHA PLUS HARDI NOVA
PP RR EE PP AA RR AA TT II OO NN
CHAPTER
33-
7
1. Place the sprayer on level position and unfold completely the
boom
3. Measure the distance (
dd))
4. Loosen nuts
AA
and remove nuts
BB
5. Place a suitable tool in the hole in the turn buckle, and use the tool
to rotate the turn buckle
Clockwise rotation
: The turn buckle becomes longer
7. Adjust the steering arm to obtain the correct setting (measured dis-
tance (
dd))
)
8. Always use the same position for both bottom steering arms
9. Check the distance (
dd))
, re-adjust if necessary
10. Tighten nuts
BB
and
AA
again
d
A
C
B
A
Lift frame
Central section
