Suction filter
Suction manifold
Pump
Pressure manifold
Agitation/Rinsing valve
Agitation tube
Safety valve
HARDI-MATIC
Self-cleaning filter return
Self-cleaning filter
Check valve
Boom section valves
Boom
Boom pressure gauge
Flush tank
HARDI chemical inductor
Tank rinse nozzles
Pressure equalization return
Boom Tube Pressure relief
Options
Ball valve
The following pictograms and colours are used for visualizing the functions of the MANIFOLD valves:
GGrreeeenn ddiisscc
= Pressure valve
BBllaacckk ddiisscc
= Suction valve
A function is activated/opened
by turning the handle towards
the desired function
- Turn the handle on a green pressure valve
towards the desired function
- Turn the handle on a black suction valve
towards the desired function
44- OOPPEERRAATTIINNGG TTHHEE LLIIQQUUIIDD SSYYSSTTEEMM
The SMART VALVES SYSTEM is located at the left side of the sprayer and permits operation of the liquid sys-
tem from one position.
44-
11
FFuunnccttiioonn ddiiaaggrraammss
19
19
18
12
10
11
8
20
20
20
2
20
21
3
11
15
9
7
17
17
6
14
13
16
5
4
1
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
44-
22
UUssee ooff MMaanniiffoolldd vvaallvvee ssyysstteemm
CClloosseedd
FFuunnccttiioonn
ooppeenn
44-
33
TToo ooppeerraattee tthhee sspprraayyiinngg ffuunnccttiioonnss
NNOOTTEE!!
If a MANIFOLD valve is too tight to operate - or ifit is
too loose (= liquid leakage), the valve needs to be serviced.
Please see the part "Occasional maintenance - Adjustment of
3-way-valve" for further information. Correct setting is when
the valve can be operated smoothly by one hand
