HARDI-EVRARD ALPHA PLUS 4100 - Spraying Operations; Spraying With and Without Agitation

ALPHA PLUS TWIN FORCE
OO PP EE RR AA TT IINN GG TT HH EE LL IIQQ UU II DD SS YY SS TT EE MM
CHAPTER
44-
9
44-
11
11 SSpprraayyiinngg
Spraying WITH AGITATION
AAGGIITTAATTIIOONN // RRIINNSSIINNGG
PPRREESSSSUURREE
SSUUCCTTIIOONN
AAGGIITTAATTIIOONN // RRIINNSSIINNGG
PPRREESSSSUURREE
SSUUCCTTIIOONN
Spraying WITHOUT AGITATION
44-1122
UUssee ooff rriinnssiinngg ttaannkk aanndd rriinnssiinngg nnoozzzzlleess
Use Adjustable Agitation to adjust the needed amount of agitation related to selected praying volume.
AAGGIITTAATTIIOONN // RRIINNSSIINNGG
PPRREESSSSUURREE
SSUUCCTTIIOONN
The incorporated rinsing tank can be used for two different purposes.
AA
. In-field diluting of remaining spray liquid residue in the spraying circuit for spraying the liquid
in the field, before cleaning the sprayer.
1. Empty the sprayer as much as possible. Close the upper green pressure valve (no agitation)
and spray till air comes out of all nozzles.
2. Turn black suction valve towards "Rinsing tank".
3. Turn upper green pressure valve towards "Rinsing nozzle" (if fitted).
4. Engage and set the pump at approximately 300 r.p.m.
