ALPHA PLUS HARDI NOVA
MM AA II NN TT EE NN AA NN CC EE
CHAPTER
55-
14
677833
04/05
3322-3366 GGVVAA bboooomm aaddjjuussttmmeenntt
- Adjust the screw
((AA))
to align the outer boom section.
- Vent the ram
- Position the rod at the maximum position
- Adjust the hinge
((BB))
to get the outer section in contact with the screw-stop
((AA))
-Screw on 2-turn the hinge
((BB))
to lock the assembly
..
BB
AA
CC
BB
AA
Check the tension of the air conditioning belt, for this purpose :
- Unscrew the locknut
((11))
of the belt tightener
- Screw the nut
((22))
to tension the belt and re-fit the locknut.
- Check the tension after
1155
mn use.
22
11
