HARDKORR HYPERION Series - Wiring Diagram

7WIRING DIAGRAM
CABIN-MOUNTED SWITCH
12/24V RELAY
FACTORY
HIGH-BEAM
CABLE
HIGH-BEAM
PIGGYBACK
ADAPTER
TO FUSE BOX
WHITE CABLE END = WHITE DRL
YELLOW CABLE END = ORANGE DRL
USE THE APPROPRIATE BLADE FUSE ADAPTER SIZE FOR YOUR VEHICLE
BATTERY CONNECTION
(WITH FUSE TOWARD BATTERY
END OF POSITIVE CABLE)
BATTERYBATTERY
