Harley-Davidson 2014 - Model Specifications

MODEL SPECIFICATIONS
1
sTrEET glidE
®
FLHX
dimensions
Length 96.5 in. (2450 mm)
Overall Width 37.8 in. (960 mm)
Overall Height 53.2 in. (1350 mm)
Seat Height:
• Laden
2
• Unladen
26.1 in. (662.94 mm)
27.4 in. (695 mm)
Ground Clearance 5.3 in.
(135 mm)
Rake (steering head) 26°
Fork Angle 29.25°
Trail 6.8 in. (172.72 mm)
Wheelbase 64 in. (1625 mm)
Tires
(Dunlop
®
Harley-Davidson
®
Series, bias blackwall front and rear):
• Front – D408F
• Rear – D407T
130/60B19 61H
BW 180/65B16 81H
Fuel Capacity
6 gal. (22.7 L)
(warning light at approximately 1.0 gal.)
Oil Capacity (w/filter) 4 qts. (3.8 L)
Transmission Capacity 1 qt. (.95 L)
Primary Chain
Case Capacity
1.4 qts. (1.3 L)
Weight:
• As Shipped
• In Running Order
• Gross Vehicle Weight
Rating
• Gross Axle Weight
Rating
• Front
• Rear
775 lbs. (352 kg)
810 lbs. (367 kg)
1360 lbs. (617 kg)
500 lbs. (227 kg)
927 lbs. (420 kg)
Luggage Capacity
• Volume
2.3 cu. ft. (0.064 m
3
)
enGine
Engine Air-cooled, High Output Twin Cam
103™ with integrated oil cooler
Valves Pushrod-operated, overhead valves
with hydraulic, self-adjusting lifters;
two valves per cylinder
Bore x Stroke 3.87 in. x 4.374 in.
(98.4 mm x 111.1 mm)
Displacement 103.1 cu. in.
(1690 cc)
Compression Ratio 9.7:1
Fuel System
3
Electronic Sequential Port Fuel Injection
(ESPFI)
Air Cleaner Paper, washable
Lubrication System Pressurized, dry-sump with oil cooler
drivetrain
Primary Drive Chain, 34/46 ratio
Final Drive Belt, 32/68 ratio
Clutch
Hydraulically actuated, 9 plate wet,
with high performance spring
Transmission 6-speed Cruise Drive
®
Gear Ratios (overall):
• 1st
• 2nd
• 3rd
• 4th
• 5th
• 6th
U.S.
9.593
6.65
4.938
4
3.407
2.875
cHassis
Frame Mild steel; tubular frame; two-piece
stamped and welded backbone; cast
and forged junctions; twin downtubes;
bolt-on rear frame with forged fender
supports; MIG welded
Swingarm Mild steel; two-piece drawn and welded
section; forged junctions; MIG welded
Front Forks 49 mm telescopic
Rear Shocks
Low air-adjustable low profile air ride
rear suspension
Wheels
4
: Enforcer Cast Aluminum
• Front
• Rear
19 in. x 3.5 in. (483 mm x 89 mm)
16 in. x 5 in. (406 mm x 127 mm)
Brakes:
• Caliper Type
• Rotor Type
(diameter x width):
• Front
(dual)
• Rear
• Anti-lock Braking
System
32 mm, 4-piston fixed front and rear
Dual floating rotors
(front), fixed rotor (rear)
11.81 in. x .2 in. (300 mm x 5.1 mm)
11.81 in. x .28 in. (300 mm x 7.1 mm)
Optional
Suspension Travel:
• Front Wheel
• Rear Wheel
4.6 in. (117 mm)
2.13 in. (54 mm)
performance
Engine Torque
5
(per J1349):
• North America 104.7 ft. lbs. @ 3250 RPM
(142 Nm @ 3250 RPM)
Lean Angle
(per J1168):
• Right
• Left
32°
31°
Fuel Economy
6
(EPA urban/highway test)
42 mpg (5.6 L/100 km)
electric
Battery (per Battery Council
International Rating)
Sealed, maintenance-free, 12V,
28-amp/hour, 405 cca
Charging Three-phase, 50-amp system
(585W @
13V, 2000 RPM, 650W max power @13V)
Starting 1.2 kW electric with solenoid shift
starter motor engagement
Lights
(as per country regulation):
• Headlamp Dual halogen headlight 55-watt
546 lumen low beam, 65-watt
1,460 lumen high beam
• Tail/Stop Lights 8W/28W
• Turn Signal Lights 28W self-canceling
• Rear Tail/Stop/Turn
Signal Lights
Fender mounted incandescent
stop/turn/tail light bar
• Front Signal Lights 8W/28W
• Indicator Lamps High beam, running lights, front fender
running lights, directional lights, low oil
pressure, engine diagnostics, neutral,
cruise control, speakers, accessory,
battery, gear indication, security
system
7
(optional), 6-speed, low fuel
warning, ABS
(optional), miles to empty
display, fog/aux lamp indicator
Electric Power Outlet Electric power accessory port in fairing
warranty
Warranty
8
24 months (unlimited mileage)
Service Interval
9
First 1000 miles (1600 km), every
5000 miles (8000 km) thereafter
1
Vehicles depicted may differ from vehicles manufactured and delivered. Specifications and
prices listed may differ from specifications and prices of vehicles manufactured and delivered.
All product descriptions (including depictions, specifications, dimensions, measurements, ratings
and competitive comparisons) are based on available information at the time of publication.
Although such descriptions are believed correct, errors and changes can occur and complete
accuracy cannot be guaranteed. Harley-Davidson may make changes at any time to prices and
specifications, and may change or discontinue models, without notice and without incurring any
obligation. Attention: Vehicles in the configurations shown and many of the accessories described
in this catalog may not be available for sale or use in some locations. Please check with your
dealer for complete product details and the latest information. All models feature 6-speed
transmission (V-Rod
®
models and Sportster
®
models are 5-speed) and carbon fiber belt final
drive; multi-plate clutch with diaphragm spring in oil bath; and 2-year unlimited mileage warranty.
2
Measurement reflects 180 lb. (81.7 kg) operator weight.
3
Recommended 91 octane or higher fuel (R+M)/2.
4
Standard and optional wheels may vary by country and region.
5
Values shown are nominal. Performance may vary by country and region.
6
The combined fuel economy numbers were derived using a combination of estimated city and
highway values. Fuel economy estimates are derived from US EPA exhaust emission certification
data on a sample motorcycle from the corresponding family under ideal laboratory conditions.
Your actual fuel economy will vary depending on your personal riding habits, road and driving
conditions, vehicle condition and maintenance, tire pressure, vehicle configuration (parts and
accessories), and vehicle loading (cargo, rider and passenger weight). Break-in mileage may vary.
7
North America security system includes immobilizer; outside North America the security system
includes immobilizer and siren.
8
See motorcycle owner’s manual for complete details.
9
Inspections of certain systems and components are required at 2,500 mile (4,000 km) intervals.
See Owner’s Manual for full details.
