MODEL SPECIFICATIONS
1
Tri Glide
®
UlTra
FLHTCUTG
dimensions
Length 105.1 in. (2670 mm)
Overall Width 54.7 in. (1390 mm)
Overall Height 56.3 in. (1430 mm)
Seat Height:
• Laden
2
• Unladen
27.1 in.
(688 mm)
28.4 in.
(720 mm)
Ground Clearance 4.5 in.
(115 mm)
Rake (steering head) 26°
Fork Angle 32°
Trail 3.94 in. (100 mm)
Wheelbase 65.8 in. (1670 mm)
Tires (Dunlop
®
Harley-Davidson
®
Series, bias blackwall front and radial blackwall rear):
• Front – D402F
• Rear – Signature
MT90B16 72H
P205/65R15
Fuel Capacity 6 gal. (22.7 L)
(warning light at approximately 1.0 gal.)
Oil Capacity (w/filter) 4 qts. (3.8 L)
Transmission Capacity 1 qt. (.95 L)
Primary Chain
Case Capacity
1.4 qts. (1.3 L)
Coolant Capacity 1.1 qt. (1.0406 L)
Weight:
• As Shipped
• In Running Order
• Gross Vehicle
Weight Rating
• Gross Axle
Weight Rating:
• Front
• Rear
• Luggage Capacity:
• Volume
1180 lbs. (535 kg)
1215 lbs. (551 kg)
1700 lbs. (771 kg)
500 lbs. (227 kg)
1200 lbs. (544 kg)
6.8 cu. ft. (0.19 m
3
)
engine
Engine Twin-Cooled™ High Output
Twin Cam 103
™
Valves Pushrod-operated, overhead valves
with hydraulic, self-adjusting lifters;
two valves per cylinder
Bore x Stroke 3.87 in. x 4.374 in.
(98.4 mm x 111.1 mm)
Displacement 103.1 cu. in.
(1690 cc)
Compression Ratio 10:1
Fuel System
3
Electronic Sequential Port Fuel Injection
(ESPFI)
Air Cleaner Paper, washable
Lubrication System Pressurized, dry-sump
drivetrain
Primary Drive Chain, 34/46 ratio
Final Drive Belt, 30/70 ratio
Clutch Hydraulically actuated multi-plate,
wet Assist & Slip
Transmission
6-speed Cruise Drive
®
Gear Ratios (overall):
• 1st
• 2nd
• 3rd
• 4th
• 5th
• 6th
U.S.
10.534
7.302
5.423
4.392
3.741
3.157
chassis
Frame Mild steel, square-section backbone
with twin downtubes
Swingarm Mild steel, rectangular tube sections
with plate junctions; MIG welded
Front Forks 49 mm telescopic
Rear Shocks Air-adjustable
Wheels
4
: Black, 7-Spoke Cast Aluminum
• Front
• Rear
16 in. x 3 in. (406 mm x 76 mm)
15 in. x 5.5 in. (381 mm x 140 mm)
Brakes:
• Caliper Type
• Rotor Type
(diameter x width):
• Front
(dual)
• Rear
6 piston fixed front with 4-31.75 mm
front pistons and 2-25.4 mm linked
rear pistons, 31.75 mm single piston
floating rear
Dual floating rotors
(front), fixed rotor (rear)
11.81 in. x .2 in. (300 mm x 5.1 mm)
10.66 in. x .25 in. (270.8 mm x 6.2 mm)
Suspension Travel:
• Front Wheel
• Rear Wheel
4.6 in. (117 mm)
3 in. (76 mm)
Parking Brake Foot actuated dual parking brake
performance
Engine Torque
5
(per J1349):
• North America 106.2 ft. lbs. @ 3750 RPM
(144 Nm @ 3750 RPM)
Fuel Economy
6
(EPA urban/highway test)
38 mpg (6.2 L/100 km)
electric
Battery (per Battery Council
International Rating)
Sealed, maintenance-free, 12V,
28-amp/hour, 405 cca
Charging Three-phase, 50-amp system
(585W @
13V, 2000 RPM, 650W max power @ 13V)
electric (continued)
Starting 1.2 kW electric with solenoid shift
starter motor engagement
Lights
(as per country regulation):
• Headlamp LED 34-watt, 916 lumen low beam,
37-watt, 917 lumen high beam with
switchable 20-watt, 1,220 lumen LED
Fog Lamps. Total of 2,136 lumen
output at low beam with fog lights.
• Tail/Stop Lights Two @ 8W/28W
• Turn Signal Lights 28W self-canceling and Tour-Pak
®
mounted LED
• Rear Tail/Stop/Turn
Signal Lights
TourPak
®
mounted and dual fender
mounted LED stop/turn/tail
• Front Signal Lights 8W/28W
• Indicator Lamps High beam, running lights, front fender
running lights, directional lights, battery,
neutral, low oil pressure, engine
diagnostics, cruise control, speakers,
accessory, security system
7
(optional),
gear indication, low fuel warning,
reverse, park brake, miles to empty
display, fog/aux lamp indicator
• Auxiliary Lamps
(except where prohibited
by law)
Two LED @ 20W each
Electric Power Outlet Electric power accessory port in fairing
GPS System New Boom!™ Box 6.5 GT audio system
with GPS and touchscreen
Reverse Gear Electric reverse actuated by handlebar
mounted hand controls
warranty
Warranty
8
24 months (unlimited mileage)
Service Interval
9
First 1000 miles (1600 km), every
5000 miles (8000 km) thereafter
1
Vehicles depicted may differ from vehicles manufactured and delivered. Specifications and
prices listed may differ from specifications and prices of vehicles manufactured and delivered.
All product descriptions (including depictions, specifications, dimensions, measurements, ratings
and competitive comparisons) are based on available information at the time of publication.
Although such descriptions are believed correct, errors and changes can occur and complete
accuracy cannot be guaranteed. Harley-Davidson may make changes at any time to prices and
specifications, and may change or discontinue models, without notice and without incurring any
obligation. Attention: Vehicles in the configurations shown and many of the accessories described
in this catalog may not be available for sale or use in some locations. Please check with your
dealer for complete product details and the latest information. All models feature 6-speed
transmission (V-Rod
®
models and Sportster
®
models are 5-speed) and carbon fiber belt final
drive; multi-plate clutch with diaphragm spring in oil bath; and 2-year unlimited mileage warranty.
2
Measurement reflects 180 lb. (81.7 kg) operator weight.
3
Recommended 91 octane or higher fuel (R+M)/2.
4
Standard and optional wheels may vary by country and region.
5
Values shown are nominal. Performance may vary by country and region.
6
The combined fuel economy numbers were derived using a combination of estimated city and
highway values. Fuel economy estimates are derived from US EPA exhaust emission certification
data on a sample motorcycle from the corresponding family under ideal laboratory conditions.
Your actual fuel economy will vary depending on your personal riding habits, road and driving
conditions, vehicle condition and maintenance, tire pressure, vehicle configuration (parts and
accessories), and vehicle loading (cargo, rider and passenger weight). Break-in mileage may vary.
7
North America security system includes immobilizer; outside North America the security system
includes immobilizer and siren.
8
See motorcycle owner’s manual for complete details.
9
Inspections of certain systems and components are required at 2,500 mile (4,000 km) intervals.
See Owner’s Manual for full details.
