MODEL SPECIFICATIONS
1
CVO
™
BReaKOut
®
FXSBSE
dimeNSioNS
Length 96.3 in. (2445 mm)
Overall Width 38.8 in. (985 mm)
Overall Height 42.5 in. (1080 mm)
Seat Height:
• Laden
2
• Unladen
24.8 in.
(630 mm)
25.8 in.
(655 mm)
Ground Clearance 4.1 in.
(105 mm)
Rake (steering head) 35°
Fork Angle 37°
Trail 5.7 in. (145 mm)
Wheelbase 67.3 in. (1710 mm)
Tires (Dunlop
®
Harley-Davidson
®
Series, bias blackwall front and radial blackwall rear):
• Front – D408
• Rear – D407
130/60B21 63H
240/40R18 79V
Fuel Capacity 5.0 gal. (18.9 L)
(warning light at approximately 1.0 gal.)
Oil Capacity (w/filter) 3.5 qts. (3.3 L)
Transmission Capacity 1 qt. (.95 L)
Primary Chain
Case Capacity
1 qt. (.95 L)
Weight:
• As Shipped
• In Running Order
• Gross Vehicle
Weight Rating
• Gross Axle
Weight Rating:
• Front
• Rear
698 lbs. (317 kg)
728 lbs. (330 kg)
1175 lbs. (533 kg)
415 lbs. (188 kg)
760 lbs. (345 kg)
eNgiNe
Engine
Air-cooled, Twin Cam 110B
™
Valves Pushrod-operated, overhead valves
with hydraulic, self-adjusting lifters;
two valves per cylinder
Bore x Stroke 4 in. x 4.374 in.
(101.6 mm x 111.1 mm)
Displacement 110 cu. in.
(1801 cc)
Compression Ratio 9.2:1
Fuel System
3
Electronic Sequential Port Fuel Injection
(ESPFI)
Air Cleaner Screamin' Eagle
®
Heavy Breather with
chrome cover, high flow backplate,
exposed element, and rain sock
Lubrication System Pressurized, dry-sump
driveTraiN
Primary Drive Chain, 34/46 ratio
Final Drive Belt, 32/66 ratio
Clutch Hydraulically actuated, 9-plate wet,
with high-performance spring
Transmission
6-speed Cruise Drive
®
Gear Ratios (overall):
• 1st
• 2nd
• 3rd
• 4th
• 5th
• 6th
U.S.
9.311
6.454
4.793
3.882
3.307
2.79
chaSSiS
Frame Mild steel, tubular frame; rectangular
section backbone; stamped, cast and
forged junctions; MIG welded; color
matched with vehicle
Swingarm Mild steel tube sections; forged
junctions; MIG welded; color matched
with vehicle
Front Forks 49 mm telescopic
Rear Shocks Hidden, horizontal-mounted, coil-over
Wheels
4
: Contrast Chrome Turbine Custom
• Front
• Rear
21 in. x 3.5 in. (533 mm x 89 mm)
18 in. x 8 in. (457 mm x 203 mm)
Brakes:
• Caliper Type
• Rotor Type
(diameter x width):
• Front
• Rear
• Anti-lock Braking
System
4-piston fixed front; 2-piston
floating rear
Single floating Turbine™ rotor
11.5 in. x .2 in. (292 mm x 5.1 mm)
11.5 in. x .23 in. (292 mm x 5.8 mm)
Standard
Suspension Travel:
• Front Wheel
• Rear Wheel
4.6 in. (117 mm)
3.1 in. (79 mm)
performaNce
Engine Torque
5
(per J1349):
• North America 112.1 ft. lbs. @ 3500 RPM
(152 Nm @ 3500 RPM)
Lean Angle
(per J1168):
• Right
• Left
25.3°
26.2°
Fuel Economy
6
(EPA urban/highway test)
43 mpg (5.5 L/100 km)
elecTric
Battery (per Battery Council
International Rating)
Sealed, maintenance-free, 12V,
19-amp/hour, 315 cca
Charging Three-phase, 38-amp system
(439W @
13V, 2000 RPM, 489W max power @ 13V)
Starting 1.2kW electric with solenoid shift starter
motor engagement
Lights
(as per country regulation):
• Headlamp 24-watt low beam,
26-watt high beam (LED)
• Rear Tail/Stop/Turn
Signal Lights
• Front Signal Lights
• Indicator Lamps
8W/28W self-canceling
8W/28W self-canceling
High-beam, neutral, low oil pressure,
turn signals, engine diagnostics,
security system
7
, low fuel warning,
cruise control, ABS
warraNTy
Warranty
8
24 months (unlimited mileage)
Service Interval
9
First 1000 miles (1600 km), every
5000 miles (8000 km) thereafter
1
Vehicles depicted may differ from vehicles manufactured and delivered. Specifications and
prices listed may differ from specifications and prices of vehicles manufactured and delivered.
All product descriptions (including depictions, specifications, dimensions, measurements, ratings
and competitive comparisons) are based on available information at the time of publication.
Although such descriptions are believed correct, errors and changes can occur and complete
accuracy cannot be guaranteed. Harley-Davidson may make changes at any time to prices and
specifications, and may change or discontinue models, without notice and without incurring any
obligation. Attention: Vehicles in the configurations shown and many of the accessories described
in this catalog may not be available for sale or use in some locations. Please check with your
dealer for complete product details and the latest information. All models feature 6-speed
transmission (V-Rod
®
models and Sportster
®
models are 5-speed) and carbon fiber belt final
drive; multi-plate clutch with diaphragm spring in oil bath; and 2-year unlimited mileage warranty.
2
Measurement reflects 180 lb. (81.7 kg) operator weight.
3
Recommended 91 octane or higher fuel (R+M)/2.
4
Standard and optional wheels may vary by country and region.
5
Values shown are nominal. Performance may vary by country and region.
6
The combined fuel economy numbers were derived using a combination of estimated city and
highway values. Fuel economy estimates are derived from US EPA exhaust emission certification
data on a sample motorcycle from the corresponding family under ideal laboratory conditions.
Your actual fuel economy will vary depending on your personal riding habits, road and driving
conditions, vehicle condition and maintenance, tire pressure, vehicle configuration (parts and
accessories), and vehicle loading (cargo, rider and passenger weight). Break-in mileage may vary.
7
North America security system includes immobilizer; outside North America the security system
includes immobilizer and siren.
8
See motorcycle owner’s manual for complete details.
9
Inspections of certain systems and components are required at 2,500 mile (4,000 km) intervals.
See Owner’s Manual for full details.
