MODEL SPECIFICATIONS
1
CVO
™
Limited
FLHTKSE
dimeNSioNS
Length 102.4 in. (2600 mm)
Overall Width 42.9 in. (1090 mm)
Overall Height 56.7 in. (1440 mm)
Seat Height:
• Laden
2
• Unladen
28.4 in.
(720 mm)
29.1 in.
(740 mm)
Ground Clearance 5.3 in.
(135 mm)
Rake (steering head) 26°
Fork Angle 29.25°
Trail 6.7 in. (170 mm)
Wheelbase 64 in. (1625 mm)
Tires (Dunlop
®
Harley-Davidson
®
Series, bias blackwall front and rear):
• Front – D408F
• Rear – D407T
BW 130/80B17 65H
BW 180/65B16 81H
Fuel Capacity 6 gal. (22.7 L)
(warning light at approximately 1.0 gal.)
Oil Capacity (w/filter) 4 qts. (3.8 L)
Transmission Capacity 1 qt. (.95 L)
Primary Chain
Case Capacity
1.4 qt. (1.3 L)
Coolant Capacity 1.1 qt. (1.04 L)
Weight:
• As Shipped
• In Running Order
• Gross Vehicle
Weight Rating
• Gross Axle
Weight Rating:
• Front
• Rear
909 lbs. (412 kg)
944 lbs. (428 kg)
1360 lbs. (617 kg)
500 lbs. (227 kg)
927 lbs. (420 kg)
Luggage Capacity
-Volume
4.7 cu. ft. (0.132 m
3
)
eNgiNe
Engine Twin-Cooled™ Twin Cam 110™
Valves Pushrod-operated, overhead valves
with hydraulic, self-adjusting lifters;
two valves per cylinder
Bore x Stroke 4 in. x 4.374 in.
(101.6 mm x 111.1 mm)
Displacement 110 cu. in.
(1801 cc)
Compression Ratio 9.2:1
Fuel System
3
Electronic Sequential Port Fuel Injection
(ESPFI)
Air Cleaner Ventilator intake with chrome cover,
fiberglass media, washable exposed
element with rain sock
Lubrication System Pressurized, dry-sump
driveTraiN
Primary Drive Chain, 34/46 ratio
Final Drive Belt, 32/68 ratio
Clutch Hydraulically actuated multi-plate,
wet Assist & Slip
Transmission
6-speed Cruise Drive
®
Gear Ratios (overall):
• 1st
• 2nd
• 3rd
• 4th
• 5th
• 6th
U.S.
9.593
6.65
4.938
4
3.407
2.875
chaSSiS
Frame Mild steel; tubular frame; two-piece
stamped and welded backbone; cast
and forged junctions; twin downtubes;
bolt-on rear frame with forged fender
supports; MIG welded
Swingarm Mild steel; two-piece drawn and welded
section; forged junctions; MIG welded
Front Forks 49 mm telescopic, triple-circuit damping
Rear Shocks Air-adjustable full travel air ride
rear suspension
Wheels
4
: Mirror Chrome Chisel Custom
• Front
• Rear
17 in. x 3 in. (432 mm x 76 mm)
16 in. x 5 in. (406 mm x 127 mm)
Brakes:
• Caliper Type
• Rotor Type
(diameter x width):
• Front
(dual)
• Rear
• Anti-lock Braking
System
32 mm, 4-piston fixed front and rear
Dual floating rotors
(front), fixed rotor (rear)
11.81 in. x .2 in. (300 mm x 5.1 mm)
11.81 in. x .28 in. (300 mm x 7.1 mm)
Standard
Suspension Travel:
• Front Wheel
• Rear Wheel
4.6 in. (117 mm)
3 in. (76 mm)
performaNce
Engine Torque
5
(per J1349):
• North America 115.1 ft. lbs. @ 3750 RPM
(156 Nm @ 3750 RPM)
Lean Angle
(per J1168):
• Right
• Left
31.9°
31.8°
Fuel Economy
6
(EPA urban/highway test)
41 mpg (5.7 L/100 km)
elecTric
Battery (per Battery Council
International Rating)
Sealed, maintenance-free, 12V,
28-amp/hour, 405 cca
Charging Three-phase, 53-amp system
(617W @
13V, 2000 RPM, 690W max power @ 13V)
Starting 1.2 kW electric with solenoid shift
starter motor engagement
Lights
(as per country regulation):
• Headlamp: LED 34-watt, 916 lumen low beam, 37-watt, 917
lumen high beam with switchable 20-watt, 1,220 lumen LED fog
lamps. Total of 2,136 lumen output at low beam with fog lights.
• Tail/Stop Lights LED
• Turn Signal Lights TourPak
®
mounted LED and
28W self-canceling
• Rear Tail/Stop/Turn
Signal Lights
TourPak
®
mounted LED stop/turn/tail
light bar
• Front Signal Lights 8W/28W
• Indicator Lamps: High beam, running lights, front fender
running lights, directional lights, neutral, low oil pressure,
engine diagnostics, accessory, speakers, turn signals,
security system
7
(optional), gear indication, battery, low fuel
warning, cruise control
(optional), ABS (optional), miles to empty
display, fog/aux lamp indicator
• Auxiliary Lamps
(except
where prohibited by law)
Two LED @ 20W each
Electric Power Outlet Electric power accessory port in
fairing and TourPak
®
GPS System New Boom!™ Box 6.5GT audio system
with GPS and touchscreen
warraNTy
Warranty
8
24 months (unlimited mileage)
Service Interval
9
First 1000 miles (1600 km), every
5000 miles (8000 km) thereafter
1
Vehicles depicted may differ from vehicles manufactured and delivered. Specifications and
prices listed may differ from specifications and prices of vehicles manufactured and delivered.
All product descriptions (including depictions, specifications, dimensions, measurements, ratings
and competitive comparisons) are based on available information at the time of publication.
Although such descriptions are believed correct, errors and changes can occur and complete
accuracy cannot be guaranteed. Harley-Davidson may make changes at any time to prices and
specifications, and may change or discontinue models, without notice and without incurring
any obligation. Attention: Vehicles in the configurations shown and many of the accessories
described in this catalog may not be available for sale or use in some locations. Please check with
your dealer for complete product details and the latest information. All models feature 6-speed
transmission (V-Rod
®
models and Sportster
®
models are 5-speed) and carbon fiber belt final drive;
multi-plate clutch with diaphragm spring in oil bath; and 2-year unlimited mileage warranty.
2
Measurement reflects 180 lb. (81.7 kg) operator weight.
3
Recommended 91 octane or higher fuel (R+M)/2.
4
Standard and optional wheels may vary by country and region.
5
Values shown are nominal. Performance may vary by country and region.
6
The combined fuel economy numbers were derived using a combination of estimated city and
highway values. Fuel economy estimates are derived from US EPA exhaust emission certification
data on a sample motorcycle from the corresponding family under ideal laboratory conditions.
Your actual fuel economy will vary depending on your personal riding habits, road and driving
conditions, vehicle condition and maintenance, tire pressure, vehicle configuration (parts and
accessories), and vehicle loading (cargo, rider and passenger weight). Break-in mileage may vary.
7
North America security system includes immobilizer; outside North America the security system
includes immobilizer and siren.
8
See motorcycle owner’s manual for complete details.
9
Inspections of certain systems and components are required at 2,500 mile (4,000 km) intervals.
See Owner’s Manual for full details.
