MODEL SPECIFICATIONS
1
CVO
™
SOftaiL
®
deLuxe
FLSTNSE
dimeNSioNS
Length 95.7 in. (2430 mm)
Overall Width 39.2 in. (995 mm)
Overall Height 57.3 in. (1455 mm)
Seat Height:
• Laden
2
• Unladen
24 in.
(610 mm)
25.8 in.
(655 mm)
Ground Clearance 4.7 in.
(120 mm)
Rake (steering head) 32.1°
Fork Angle 32°
Trail 5.8 in. (147 mm)
Wheelbase 64.2 in. (1630 mm)
Tires (Dunlop
®
Harley-Davidson
®
Series, wide whitewall):
• Front – D402F WW
• Rear – D402 WW
MT90B16 M/C 72H
MU85B16 77H
Fuel Capacity 5.0 gal. (18.9 L)
(warning light at approximately 1.0 gal.)
Oil Capacity (w/filter) 3.5 qts. (3.31 L)
Transmission Capacity 1 qt. (.95 L)
Primary Chain
Case Capacity
1 qts. (.95 L)
Weight:
• As Shipped
• In Running Order
• Gross Vehicle
Weight Rating
• Gross Axle
Weight Rating:
• Front
• Rear
749 lbs. (340 kg)
782 lbs. (355 kg)
1160 lbs. (526 kg)
430 lbs. (195 kg)
730 lbs. (331 kg)
Luggage Capacity
-Volume
1.79 cu. ft. (0.0501 m
3
)
eNgiNe
Engine Air-cooled, Twin Cam 110B™
Valves Pushrod-operated, overhead valves
with hydraulic, self-adjusting lifters;
two valves per cylinder
Bore x Stroke 4 in. x 4.374 in.
(101.6 mm x 111.1 mm)
Displacement 110 cu. in.
(1801 cc)
Compression Ratio 9.2:1
Fuel System
3
Electronic Sequential Port Fuel Injection
(ESPFI)
Air Cleaner Ventilator intake with chrome cover,
fiberglass media, washable exposed
element with rain sock
Lubrication System Pressurized, dry-sump
driveTraiN
Primary Drive Chain, 34/46 ratio
Final Drive Belt, 32/66 ratio
Clutch Hydraulically actuated, 9-plate wet,
with high-performance spring
Transmission
6-speed Cruise Drive
®
Gear Ratios (overall):
• 1st
• 2nd
• 3rd
• 4th
• 5th
• 6th
U.S.
9.311
6.454
4.793
3.882
3.307
2.79
chaSSiS
Frame Mild steel, tubular frame; rectangular
section backbone; stamped, cast and
forged junctions; MIG welded; color
coordinated with vehicle
Swingarm Mild steel tube sections;
forged junctions; MIG welded;
color coordinated with vehicle
Front Forks 41.3 mm telescopic, chrome upper
fork-slider covers
Rear Shocks Hidden, horizontal-mounted, coil-over
Wheels
4
: Chrome, 9-Spoke Cast Aluminum
• Front
• Rear
16 in. x 3 in. (406 mm x 76 mm)
16 in. x 3 in. (406 mm x 76 mm)
Brakes:
• Caliper Type 4-piston fixed front; 2-piston floating rear
• Rotor Type
(diameter x width):
Single floating Turbine
™
rotor
• Front
• Rear
11.5 in. x .2 in. (292 mm x 5.1 mm)
11.5 in. x .23 in. (292 mm x 5.8 mm)
• Anti-lock Braking
System
Standard
Suspension Travel:
• Front Wheel
• Rear Wheel
5.1 in. (130 mm)
3.6 in. (91 mm)
performaNce
Engine Torque
5
(per J1349):
• North America 107.7 ft. lbs. @ 3000 RPM
(146 Nm @ 3000 RPM)
Lean Angle
(per J1168):
• Right
• Left
25.8°
26.7°
Fuel Economy
6
(EPA urban/highway test)
43 mpg (5.5 L/100 km)
elecTric
Battery (per Battery Council
International Rating)
Sealed, maintenance-free, 12V,
19-amp/hour, 270 cca
Charging Three-phase, 38-amp system
(439W @
13V, 2000 RPM, 489W max power @ 13V)
Starting 1.2kW electric with solenoid shift starter
motor engagement
Lights
(as per country regulation):
• Headlamp LED 34-watt, 916 lumen low beam,
37-watt, 917 lumen high beam with
switchable 20-watt, 1220 lumen,LED
Fog Lamps for a total of 2136 lumen
output at low beam with fog lights
• Rear Tail/Stop/Turn
Signal Lights
28W/21W Incandescent
stop/turn/tail signal lights
(self cancelling) with red lenses
• Front Signal Lights
Incandescent front turn signals with
smoked lenses
• Indicator Lamps High beam, running lights, neutral,
low oil pressure, engine diagnostics,
turn signals, security system
7
, 6-speed,
low fuel warning, cruise control, ABS
warraNTy
Warranty
8
24 months (unlimited mileage)
Service Interval
9
First 1000 miles (1600 km), every
5000 miles (8000 km) thereafter
1
Vehicles depicted may differ from vehicles manufactured and delivered. Specifications and
prices listed may differ from specifications and prices of vehicles manufactured and delivered.
All product descriptions (including depictions, specifications, dimensions, measurements, ratings
and competitive comparisons) are based on available information at the time of publication.
Although such descriptions are believed correct, errors and changes can occur and complete
accuracy cannot be guaranteed. Harley-Davidson may make changes at any time to prices and
specifications, and may change or discontinue models, without notice and without incurring any
obligation. Attention: Vehicles in the configurations shown and many of the accessories described
in this catalog may not be available for sale or use in some locations. Please check with your
dealer for complete product details and the latest information. All models feature 6-speed
transmission (V-Rod
®
models and Sportster
®
models are 5-speed) and carbon fiber belt final
drive; multi-plate clutch with diaphragm spring in oil bath; and 2-year unlimited mileage warranty.
2
Measurement reflects 180 lb. (81.7 kg) operator weight.
3
Recommended 91 octane or higher fuel (R+M)/2.
4
Standard and optional wheels may vary by country and region.
5
Values shown are nominal. Performance may vary by country and region.
6
The combined fuel economy numbers were derived using a combination of estimated city and
highway values. Fuel economy estimates are derived from US EPA exhaust emission certification
data on a sample motorcycle from the corresponding family under ideal laboratory conditions.
Your actual fuel economy will vary depending on your personal riding habits, road and driving
conditions, vehicle condition and maintenance, tire pressure, vehicle configuration (parts and
accessories), and vehicle loading (cargo, rider and passenger weight). Break-in mileage may vary.
7
North America security system includes immobilizer; outside North America the security system
includes immobilizer and siren.
8
See motorcycle owner’s manual for complete details.
9
Inspections of certain systems and components are required at 2,500 mile (4,000 km) intervals.
See Owner’s Manual for full details.
