MODEL SPECIFICATIONS
1
Road King
®
FIRE/RESCUE FLHP
dimensions
Length 96.5 in. (2450 mm)
Overall Width 37.8 in.
(960 mm)
Overall Height 56.3 in.
(1430 mm)
Seat Height:
• Laden
2
• Unladen
27.3 in.
(695 mm)
31.1 in.
(790 mm)
Ground Clearance 5.3 in.
(135 mm)
Rake (steering head) 26°
Fork Angle 29.25°
Trail 6.7 in.
(170 mm)
Wheelbase 64 in.
(1625 mm)
Tires
(Dunlop
®
Harley-Davidson
®
Series, bias blackwall front and rear):
• Front – D408F
• Rear – D407T
BW 130/80B17 65H
BW 180/65B16 81H
Bead-retention tires designed to remain on wheel during sudden loss
of pressure. Sealed, automotive-style wheel bearings requiring no end
play adjustments and service interval of 100,000 miles (160,000 km).
Fuel Capacity 6 gal. (22.7 L)
(warning light at approximately 1 gal.)
Oil Capacity (with filter) 4 qts. (3.8 L)
Transmission Capacity 1 qt. (.95 L)
Primary Chain
Case Capacity
1.4 qts. (1.3 L)
Weight:
• As Shipped
• In Running Order
• Gross Vehicle Weight
Rating
786 lbs. (357 kg)
821 lbs. (372 kg)
1360 lbs. (617 kg)
• Gross Axle Weight Rating:
• Front
• Rear
500 lbs. (227 kg)
927 lbs. (420 kg)
Luggage Capacity
• Volume
2.3 cu. ft. (0.064 m
3
)
engine
Engine Air-cooled, High Output Twin Cam
103™ with integrated oil cooler
Valves Pushrod-operated, overhead valves
with hydraulic, self-adjusting lifters;
two valves per cylinder
Bore x Stroke 3.87 in. x 4.38 in. (98.4 mm x 111.1 mm)
Displacement 103.1 cu. in.
(1690 cc)
Compression Ratio 9.7:1
Fuel System
3
Electronic Sequential Port Fuel Injection
(ESPFI)
Air Cleaner Fiberglass, washable
Lubrication System Pressurized, dry-sump with oil cooler
electric
Battery (per Battery Council
International Rating)
Sealed, maintenance-free, 12V,
28-amp/hour, 405 cca
Charging Three-phase, 50-amp system
(585W @
13V, 2000 RPM, 650W max power @ 13V)
Starting 1.2 kW electric with solenoid shift
starter motor engagement
Lights
(as per country regulation):
• Headlamp (dual halogen)
• Tail/Stop Lights
• Turn Signal Lights
• Emergency Lamps
• Flashers
• Indicator Lamps
7
55-watt 546 lumen low beam,
65-watt 1,460 lumen high beam
8W/28W
28W self-canceling
Front-mounted PAR-36 lamps,
one red, one blue, incandescent
Four-way, independent switch on
right hand control
High beam, turn signals, neutral, low
oil pressure, engine diagnostics, low
fuel, battery, directional lights, police
emergency light activation
• Auxiliary Lamps Optional additional emergency light
kits available, including engine guard
and pole mounted lights
• Electric Power Outlet Electric power accessory connector
under seat
warranty
Warranty
8
24 months (unlimited mileage)
Service Interval
9
First 1000 miles (1600 km), every
5000 miles (8000 km) thereafter
1
Vehicles depicted may differ from vehicles manufactured and delivered. Specifications and
prices listed may differ from specifications and prices of vehicles manufactured and delivered. All
product descriptions (including depictions, specifications, dimensions, measurements, ratings and
competitive comparisons) are based on available information at the time of publication. Although
such descriptions are believed correct, errors and changes can occur and complete accuracy cannot
be guaranteed. Harley-Davidson may make changes at any time to prices and specifications, and
may change or discontinue models, without notice and without incurring any obligation. Attention:
Vehicles in the configurations shown and many of the accessories described in this catalog may not
be available for sale or use in some locations. Please check with your dealer for complete product
details and the latest information. All models feature 6-speed transmission (V-Rod
®
models and
Sportster
®
models are 5-speed) and carbon fiber belt final drive; multi-plate clutch with diaphragm
spring in oil bath; and 2-year unlimited mileage warranty.
2
Measurement reflects 180 lb. (81.7 kg) operator weight.
3
Recommended 91 octane or higher fuel (R+M)/2.
4
Standard and optional wheels may vary by country and region.
5
Values shown are nominal. Performance may vary by country and region.
6
The combined fuel economy numbers were derived using a combination of estimated city and
highway values. Fuel economy estimates are derived from US EPA exhaust emission certification
data on a sample motorcycle from the corresponding family under ideal laboratory conditions. Your
actual fuel economy will vary depending on your personal riding habits, road and driving conditions,
vehicle condition and maintenance, tire pressure, vehicle configuration (parts and accessories), and
vehicle loading (cargo, rider and passenger weight). Break-in mileage may vary.
8
See motorcycle owner’s manual for complete details.
9
Inspections of certain systems and components are required at 2,500 mile (4,000 km) intervals.
See Owner’s Manual for full details.
drivetrain
Primary Drive Chain, 34/46 ratio
Final Drive Belt, 32/68 ratio
Clutch Cable actuated, 9 plate wet,
with high performance spring
Transmission 6-speed Cruise Drive
®
Gear Ratios (overall):
• 1st
• 2nd
• 3rd
• 4th
• 5th
• 6th
U.S.
9.593
6.65
4.938
4
3.407
2.875
cHassis
Frame Mild steel; tubular frame; two-piece
stamped and welded backbone; cast
and forged junctions; twin downtubes;
bolt-on rear frame with forged fender
supports; MIG welded
Swingarm Mild steel, two-piece drawn and welded
section, forged junctions, MIG welded
Front Fork 49 mm telescopic
Rear Shocks Air-adjustable full travel air ride
rear suspension
Wheels
4
: Impeller Cast Aluminum
• Front
• Rear
17 in. x 3 in. (432 mm x 76 mm)
16 in. x 5 in. (406 mm x 127 mm)
Brakes:
• Caliper Type
• Rotor Type
(diameter x width):
• Front
(dual)
• Rear
• Anti-lock Braking
System
32 mm 4-piston fixed front and rear
Dual floating rotors
(front), fixed rotor (rear)
11.81 in. x 0.2 in. (300 mm x 5.1 mm)
11.81 in. x 0.28 in. (300 mm x 7.1 mm)
Standard
Suspension Travel:
• Front Wheel
• Rear Wheel
4.6 in. (117 mm)
3 in. (76 mm)
Performance
Engine Torque
5
(per J1349):
• North America 104.7 ft. lbs. @ 3250 RPM
(142 Nm @ 3250 RPM)
Lean Angle
(per J1168):
• Right
• Left
32.8°
32.3°
Fuel Economy
6
(EPA urban/highway test)
42 mpg (5.6 L/100 km)
