Harley-Davidson 2014 - Sportster Family Specs At-A-Glance

SPECS AT-A-GLANCE
SportSter
®
Family
specification
Xl 883l
superlow
®
Xl 883n
iron 883
™
Xl 1200c sportster
®
1200 custom
®
Xl 1200X
forty-eight
®
Xl 1200v
seventy-two
®
Length 87.2 in. (2215 mm) 88.8 in. (2255 mm) 87.6 in. (2225 mm) 88.8 in. (2255 mm) 89.6 in. (2275 mm)
Seat Height
(laden)
1
25.5 in. (648 mm) 25.7 in. (653 mm) 26.6 in. (676 mm) 26 in. (660 mm) 26.6 in. (675 mm)
Seat Height
(unladen) 27.4 in. (695 mm) 28.9 in. (735 mm) 28 in. (710 mm) 28 in. (710 mm) 28 in. (710 mm)
Ground Clearance 3.9 in. (100 mm) 4.7 in. (120 mm) 4.3 in. (110 mm) 3.9 in. (100 mm) 4.7 in. (120 mm)
Rake (steering head) 31.1° 30.5° 30° 30° 30.1°
Fork Angle 29.7° 30.5° 30° 30° 30.1°
Trail 5.7 in. (145 mm) 4.6 in. (117 mm) 4.2 in. (107 mm) 4.2 in. (107 mm) 5.3 in. (135 mm)
Wheelbase 59.1 in. (1500 mm) 59.5 in. (1510 mm) 59.8 in. (1520 mm) 59.8 in. (1520 mm) 60 in. (1525 mm)
Weight (as shipped) 540 lbs. (245 kg) 540 lbs. (245 kg) 562 lbs. (255 kg) 540 lbs. (245 kg) 540 lbs. (245 kg)
Engine Air-cooled, Evolution
®
Air-cooled, Evolution
®
Air-cooled, Evolution
®
Air-cooled, Evolution
®
Air-cooled, Evolution
®
Displacement 53.9 cu. in. (883 cc) 53.9 cu. in. (883 cc) 73.4 cu. in. (1202 cc) 73.4 cu. in. (1202 cc) 73.4 cu. in. (1202 cc)
Fuel System
2
Electronic Sequential Port Fuel
Injection (ESPFI)
Electronic Sequential Port Fuel
Injection (ESPFI)
Electronic Sequential Port Fuel
Injection (ESPFI)
Electronic Sequential Port Fuel
Injection (ESPFI)
Electronic Sequential Port Fuel
Injection (ESPFI)
Fuel Capacity 4.5 gal. (17 L) 3.3 gal. (12.5 L) 4.5 gals. (17 L) 2.1 gal. (7.9 L) 2.1 gal. (7.9 L)
Tire Size:
• Front
• Rear
Scorcher
®
“11F”
120/70 ZR-18 59W
Scorcher
®
“11”
150/60 ZR-17 66W
Scorcher
®
“31”
100/90B19 57H
Scorcher
®
“31”
150/80B16 77H
Scorcher
®
“31”
130/90B16 72H
Scorcher
®
“31”
150/80B16 77H
Scorcher
®
“31”
130/90B16 73H
Scorcher
®
“31”
150/80B16 77H
Dunlop
®
Harley-Davidson Series,
narrow whitewall
D402F MH90-21 54H
Dunlop
®
Harley-Davidson Series,
narrow whitewall
D401 150/80B16 71H
Wheels
3
18-inch front;
17-inch rear
Black Split 5-Spoke with
Machined Rim
19-inch front;
16-inch rear
Black 13-Spoke Cast Aluminum
16-inch front;
16-inch rear
Chrome 5-Spoke
Cast Aluminum
16-inch front;
16-inch rear
Black Steel Laced
21-inch front;
16-inch rear
Steel Laced
Lean Angle
(per J1168) (right/left)
24.7°/24.4° 29°/30° 26.2°/28.3° 27.8°/26.1° 28.6°/29.8°
Note: The vehicles in the configuration shown in this reference
guide are not available for sale and use in several countries
outside of the U.S. Please check with your local dealer for
details. We reserve the right to discontinue models or change
specifications at any time without incurring any obligations.
The vehicles pictured in this reference guide are for sale in
the U.S. only. Vehicle specifications may vary from country
to country depending on local laws, and some models and
accessories are not available in certain countries. Be aware
that many countries prohibit the importation, registration
and/or use of vehicles and accessories not built to their
country specifications. Check with your local dealer for details.
1
Measurement reects 180 lb. (81.7 kg) operator weight.
2
Recommended 91 octane or higher fuel (R+M)/2.
3
Standard and optional wheels may vary by country and region.
