MODEL SPECIFICATIONS
1
Superlow
®
XL 883L
dimensions
Length 87.2 in. (2215 mm)
Overall Width 33.3 in. (845 mm)
Overall Height 43.9 in. (1115 mm)
Seat Height:
• Laden
2
• Unladen
25.5 in.
(648 mm)
27.4 in.
(695 mm)
Ground Clearance 3.9 in.
(100 mm)
Rake (steering head) 31.1°
Fork Angle 29.7°
Trail 5.7 in. (145 mm)
Wheelbase 59.1 in. (1500 mm)
Tires (Michelin
®
Scorcher
®
“11” front and rear):
• Front – Scorcher
®
“11F”
• Rear – Scorcher
®
“11”
120/70 ZR-18 59W
150/60 ZR-17 66W
Fuel Capacity
4.5 gal. (17 L)
(warning light at approximately 1.0 gal.)
Oil Capacity (w/filter) 2.8 qts. (2.6 L)
Transmission Capacity 1 qt. (.95 L)
Weight:
• As Shipped
• In Running Order
• Gross Vehicle Weight
Rating
• Gross Axle Weight
Rating
• Front
• Rear
540 lbs. (245 kg)
562 lbs. (255 kg)
1000 lbs. (454 kg)
339 lbs. (154 kg)
661 lbs. (300 kg)
engine
Engine Air-cooled, Evolution
®
Valves Pushrod-operated, overhead valves
with hydraulic, self-adjusting lifters;
two valves per cylinder
Bore x Stroke 3 in. x 3.811 in.
(76.2 mm x 96.8 mm)
Displacement 53.9 cu. in.
(883 cc)
Compression Ratio 9:1
Fuel System
3
Electronic Sequential Port Fuel Injection
(ESPFI)
Air Cleaner Paper cartridge type
Lubrication System Dry-sump
drivetrain
Primary Drive Chain, 34/57 ratio
Final Drive Belt, 29/68 ratio
Clutch Multi-plate, wet
Transmission 5-speed
Gear Ratios
(overall):
• 1st
• 2nd
• 3rd
• 4th
• 5th
U.S.
10.41
7.436
5.531
4.584
3.931
chassis
Frame Mild steel, tubular frame; circular
sections; cast junctions
Swingarm Mild steel, rectangular tube section,
stamped junctions; MIG welded
Front Forks 39 mm Showa
®
Rear Shocks Coil-over; preload dual-adjustable
Wheels
4
: Black Split 5-Spoke
with Machined Rim
• Front
• Rear
18 in. x 3.5 in. (457 mm x 89 mm)
17 in. x 4.5 in. (432 mm x 114 mm)
Brakes:
• Caliper Type
• Rotor Type
(diameter x width):
• Front
• Rear
• Anti-lock Braking
System
Dual-piston front, dual-piston rear
Solid, uniform expansion rotors
11.8 in. x .2 in. (300 mm x 5.1 mm)
10.24 in. x .28 in. (260.1 mm x 7.1 mm)
Optional
Suspension Travel:
• Front Wheel
• Rear Wheel
4.26 in. (108 mm)
2.12 in. (54 mm)
performance
Engine Torque
5
(per J1349):
• North America 53.8 ft. lbs. @ 3750 RPM
(73 Nm @ 3750 RPM)
Lean Angle
(per J1168):
• Right
• Left
24.7°
24.4°
Fuel Economy
6
(EPA urban/highway test)
51 mpg (4.6 L/100 km)
electric
Battery (per Battery Council
International Rating)
Sealed lead acid, maintenance-free,
12V, 12 amp/hour, 200 cca
Charging Single-phase, 30-amp system
(375W @
13.5V, 2000 RPM, 405W max power @ 13.5V)
Starting 1.2 kW electric with solenoid shift
starter motor engagement
Lights
(as per country regulation):
• Headlamp
(quartz halogen)
55-watt low beam,
60-watt high beam
• Tail/Stop Lights
• Turn Signal Lights
• Indicator Lamps
8W/28W per lamp
28W self-canceling
High beam, neutral, low oil pressure,
turn signals, engine diagnostics,
low fuel warning, low battery, security
system
7
(optional)
warranty
Warranty
8
24 months (unlimited mileage)
Service Interval
9
First 1000 miles (1600 km), every
5000 miles (8000 km) thereafter
1
Vehicles depicted may differ from vehicles manufactured and delivered. Specifications and
prices listed may differ from specifications and prices of vehicles manufactured and delivered.
All product descriptions (including depictions, specifications, dimensions, measurements, ratings
and competitive comparisons) are based on available information at the time of publication.
Although such descriptions are believed correct, errors and changes can occur and complete
accuracy cannot be guaranteed. Harley-Davidson may make changes at any time to prices and
specifications, and may change or discontinue models, without notice and without incurring any
obligation. Attention: Vehicles in the configurations shown and many of the accessories described
in this catalog may not be available for sale or use in some locations. Please check with your
dealer for complete product details and the latest information. All models feature 6-speed
transmission (V-Rod
®
models and Sportster
®
models are 5-speed) and carbon fiber belt final
drive; multi-plate clutch with diaphragm spring in oil bath; and 2-year unlimited mileage warranty.
2
Measurement reflects 180 lb. (81.7 kg) operator weight.
3
Recommended 91 octane or higher fuel (R+M)/2.
4
Standard and optional wheels may vary by country and region.
5
Values shown are nominal. Performance may vary by country and region.
6
The combined fuel economy numbers were derived using a combination of estimated city and
highway values. Fuel economy estimates are derived from US EPA exhaust emission certification
data on a sample motorcycle from the corresponding family under ideal laboratory conditions.
Your actual fuel economy will vary depending on your personal riding habits, road and driving
conditions, vehicle condition and maintenance, tire pressure, vehicle configuration (parts and
accessories), and vehicle loading (cargo, rider and passenger weight). Break-in mileage may vary.
7
North America security system includes immobilizer; outside North America the security system
includes immobilizer and siren.
8
See motorcycle owner’s manual for complete details.
9
Inspections of certain systems and components are required at 2,500 mile (4,000 km) intervals.
See Owner’s Manual for full details.
