MODEL SPECIFICATIONS
1
Heritage Softail
®
ClaSSiC
FLSTC
Dimensions
Length 94.7 in. (2405 mm)
Overall Width 37.6 in. (955 mm)
Overall Height 55.4 in. (1408 mm)
Seat Height:
• Laden
2
• Unladen
25.5 in.
(648 mm)
27.2 in.
(690 mm)
Ground Clearance 5.2 in.
(131 mm)
Rake (steering head) 31°
Fork Angle 31°
Trail 5.8 in. (147 mm)
Wheelbase 64.4 in. (1635 mm)
Tires (Dunlop
®
Harley-Davidson
®
Series, bias blackwall front and rear):
• Front – D402F
• Rear – D401
MT90B16 72H
150/80B16 71H
Fuel Capacity
5 gal. (18.9 L)
(warning light at approximately 1.0 gal.)
Oil Capacity (w/filter) 3.5 qts. (3.3 L)
Transmission Capacity 1 qt. (.95 L)
Primary Chain
Case Capacity
1 qt. (.95 L)
Weight:
• As Shipped
• In Running Order
• Gross Vehicle
Weight Rating
• Gross Axle
Weight Rating:
• Front
• Rear
730 lbs. (331 kg)
761 lbs. (345 kg)
1160 lbs. (526 kg)
430 lbs. (195 kg)
730 lbs. (331 kg)
engine
Engine Air-cooled, Twin Cam 103B
TM
Valves Pushrod-operated, overhead valves
with hydraulic, self-adjusting lifters;
two valves per cylinder
Bore x Stroke 3.87 in. x 4.374 in.
(98.4 mm x 111.1 mm)
Displacement 103.1 cu. in.
(1690 cc)
Compression Ratio 9.6:1
Fuel System
3
Electronic Sequential Port Fuel Injection
(ESPFI)
Air Cleaner Paper, washable
Lubrication System Pressurized, dry-sump
Drivetrain
Primary Drive Chain, 34/46 ratio
Final Drive Belt, 32/66 ratio
Clutch Multi-plate, wet
Transmission 6-speed Cruise Drive
®
Gear Ratios (overall):
• 1st
• 2nd
• 3rd
• 4th
• 5th
• 6th
U.S.
9.311
6.454
4.793
3.882
3.307
2.79
cHassis
Frame Mild steel tubular frame; rectangular
section backbone; stamped, cast,
and forged junctions; forged fender
supports; MIG welded
Swingarm Mild steel, round tube sections,
forged junctions; MIG welded
Front Forks 41.3 mm telescopic, “beer can” covers
Rear Shocks Hidden, horizontal-mounted, coil-over
Wheels
4
(Tubeless, Chrome
Aluminum Profile Laced option)
:
Steel Laced
• Front
• Rear
16 in. x 3 in. (406 mm x 76 mm)
16 in. x 3 in. (406 mm x 76 mm)
Brakes:
• Caliper Type
• Rotor Type
(diameter x width):
• Front
• Rear
• Anti-lock Braking
System
4-piston front and 2-piston rear
Patented, uniform expansion rotors
11.5 in. x .2 in. (292 mm x 5.1 mm)
11.5 in. x .23 in. (292 mm x 5.8 mm)
Standard
Suspension Travel:
• Front Wheel
• Rear Wheel
5.1 in. (130 mm)
4.3 in. (109 mm)
performance
Engine Torque
5
(per J1349):
• North America 95.2 ft. lbs. @ 3000 RPM
(129 Nm @ 3000 RPM)
Lean Angle (per J1168):
• Right
• Left
24.4°
25.9°
Fuel Economy
6
(EPA urban/highway test)
42 mpg (5.6 L/100 km)
electric
Battery (per Battery Council
International Rating)
Sealed, maintenance-free, 12V,
19-amp/hour, 270 cca
Charging Three-phase, 38-amp system
(439W @
13V, 2000 RPM, 489W max power @ 13V)
Starting 1.2 kW electric with solenoid shift
starter motor engagement
Lights
(as per country regulation):
• Headlamp
(quartz halogen)
55-watt low beam,
60-watt high beam
• Tail/Stop Lights
• Turn Signal Lights
• Indicator Lamps
8W/28W (5W/21W)
28W (21W) self-canceling
High beam, front fender running lights,
neutral, low oil pressure, turn signals,
engine diagnostics, security system
7
(optional)
, 6-speed, low fuel warnings
warranty
Warranty
8
24 months (unlimited mileage)
Service Interval
9
First 1000 miles (1600 km), every
5000 miles (8000 km) thereafter
1
Vehicles depicted may differ from vehicles manufactured and delivered. Specifications and
prices listed may differ from specifications and prices of vehicles manufactured and delivered.
All product descriptions (including depictions, specifications, dimensions, measurements, ratings
and competitive comparisons) are based on available information at the time of publication.
Although such descriptions are believed correct, errors and changes can occur and complete
accuracy cannot be guaranteed. Harley-Davidson may make changes at any time to prices and
specifications, and may change or discontinue models, without notice and without incurring any
obligation. Attention: Vehicles in the configurations shown and many of the accessories described
in this catalog may not be available for sale or use in some locations. Please check with your
dealer for complete product details and the latest information. All models feature 6-speed
transmission (V-Rod
®
models and Sportster
®
models are 5-speed) and carbon fiber belt final
drive; multi-plate clutch with diaphragm spring in oil bath; and 2-year unlimited mileage warranty.
2
Measurement reflects 180 lb. (81.7 kg) operator weight.
3
Recommended 91 octane or higher fuel (R+M)/2.
4
Standard and optional wheels may vary by country and region.
5
Values shown are nominal. Performance may vary by country and region.
6
The combined fuel economy numbers were derived using a combination of estimated city and
highway values. Fuel economy estimates are derived from US EPA exhaust emission certification
data on a sample motorcycle from the corresponding family under ideal laboratory conditions.
Your actual fuel economy will vary depending on your personal riding habits, road and driving
conditions, vehicle condition and maintenance, tire pressure, vehicle configuration (parts and
accessories), and vehicle loading (cargo, rider and passenger weight). Break-in mileage may vary.
7
North America security system includes immobilizer; outside North America the security system
includes immobilizer and siren.
8
See motorcycle owner’s manual for complete details.
9
Inspections of certain systems and components are required at 2,500 mile (4,000 km) intervals.
See Owner’s Manual for full details.
