GENERAL 1.1
REPAIR NOTES
General maintenance practices are given in this section. All
special tools and torque values are noted at the point of use
and all required parts or materials can be found in the appro-
priate PARTS CATALOG.
Safety
Safety is always the most important consideration when per-
forming any job. Be sure you have a complete understanding
of the task to be performed. Use common sense. Use the
proper tools. Don’t just do the job – do the job safely.
Removing Parts
Always consider the weight of a part when lifting. Use a hoist
whenever necessary. Do not lift heavy parts by hand. A hoist
and adjustable lifting beam or sling are needed to remove
some parts. The lengths of chains or cables from the hoist to
the part should be equal and parallel, and should be posi-
tioned directly over the center of the part. Be sure that no
obstructions will interfere with the lifting operation. Never
leave a part suspended in mid-air.
Always use blocking or proper stands to support the part that
has been hoisted. If a part cannot be removed, verify that all
bolts and attaching hardware have been removed. Check to
see if any parts are in the way of the part being removed.
When removing hoses, wiring or tubes, always tag each part
to ensure proper installation.
Cleaning
If you intend to reuse parts, follow good shop practice and
thoroughly clean the parts before assembly. Keep all dirt out
of parts; the unit will perform better and last longer. Seals, fil-
ters and covers are used in this motorcycle to keep out envi-
ronmental dirt and dust. These items must be kept in good
condition to ensure satisfactory operation.
Clean and inspect all parts as they are removed. Be sure all
holes and passages are clean and open. After cleaning,
cover all parts with clean lint-free cloth, paper or other mate-
rial. Be sure the part is clean when it is installed.
Always clean around lines or covers before they are
removed. Plug, tape or cap holes and openings to keep out
dirt, dust and debris.
Always verify cleanliness of blind holes before assembly.
Tightening screws with dirt, water or oil in the holes can
cause castings to crack or break.
Disassembly and Assembly
Always assemble or disassemble one part at a time. Do not
work on two assemblies simultaneously. Be sure to make all
necessary adjustments. Recheck your work when finished.
Be sure that everything is done.
Operate the motorcycle to perform any final check or adjust-
ments. If all is correct, the motorcycle is ready to go back to
the customer.
Checking Torques on Fasteners with Lock
Patches
To check the torque on a fastener that has a lock patch:
1. Set the torque wrench for the lowest setting in the speci-
fied torque range.
2. Attempt to tighten fastener to set torque. If fastener does
not move and lowest setting is satisfied (torque wrench
clicks), then the proper torque has been maintained.
REPAIR AND REPLACEMENT
PROCEDURES
Hardware and Threaded Parts
Install helical thread inserts when inside threads in castings
are stripped, damaged or not capable of withstanding speci-
fied torque.
Replace bolts, nuts, studs, washers, spacers and small com-
mon hardware if missing or in any way damaged. Clean up or
repair minor thread damage with a suitable tap or die.
Replace all damaged or missing lubrication fittings.
Use Teflon tape on pipe fitting threads.
Wiring, Hoses and Lines
Replace hoses, clamps, electrical wiring, electrical switches
or fuel lines if they do not meet specifications.
Instruments and Gauges
Replace broken or defective instruments and gauges.
Replace dials and glass that are so scratched or discolored
that reading is difficult.
