Level Ref. # Part Numbe
r
Description
Drawin
g
No
(
Value
)
Qt
y
UM
....5 C764 CCEA0JH102T CAP , ELECT 1000UF 6.3V 1 EA
....5 C766 CCEA0JH102T CAP , ELECT 1000UF 6.3V 1 EA
....5 D221 CVD1N4003ST DIODE , RECT 1N4003 1 EA
....5 D222 CVD1N4003ST DIODE , RECT 1N4003 1 EA
....5 Q311 HVTKTC2874BT T.R , MUTE KTC2874B 1 EA
....5 Q731 HVTKTA1267YT T.R KTA1267Y 1 EA
....5 Q733 HVTKTC3199YT T.R KTC3199Y 1 EA
...4 CQB1D022 A-ROHS/LABEL,SERIAL 1 EA
...4 BN12 CJP27GA41ZM WAFER
(
1.25MM, CARD CABLE, STRAIGHT 2
7
MOLEX 52045-**45 1 EA
...4 BN72 CJP31GA41ZM WAFER
(
1.25MM, CARD CABLE, STRAIGHT 3
1
MOLEX 52045-**45 1 EA
...4 BN81 CJP44GA240ZB PIN HEADER (44P,2.54mm), STRAIGHT TYPE 1 EA
...4 CN17 CJP06GB142ZB PIN HEADER(6P, 2.54mm) 1 EA
...4 CN20 CJP07GI237ZW LOCKING TYPE , STRAIGHT WAFER, 2.5MM 1 EA
...4 CN52 CJP03GA01ZY WAFER 1EA
...4 C732 CCEA0JH332E CAP , ELECT (KR3, 3300UF/6.3V, 10X20) KR3-6R3V332MG200-L/C4.0 1 EA
...4 IC36 HVIKIA7808API I.C , REGULATOR +8V KIA7808 (KEC) 1 EA
...4 IC37 CVIKIA7908PI I.C , REGULATOR(TO-220IS) KIA7908PI TO-220IS 1 EA
...4 JK11 CJJ4P014W JACK , IN/OUT 1EA
...4 JK12 CJJ4R019W TERMINAL , IN/OUT 1 EA
...4 JK13 CJJ4R019W TERMINAL , IN/OUT 1 EA
...4 JK14 CJJ4R037W JACK , BOARD 1EA
...4 JK78 CJJ4S022Z JACK , BOARD 1EA
...4 JW70 CWE8202150AA WIRE ASS'Y 1EA
...4 L301 CLM4B001Z COIL , MPX (FM 19KHz FILTER) 1 EA
...4 L302 CLM4B001Z COIL , MPX (FM 19KHz FILTER) 1 EA
...4 TUN1 CNVMW104MV1S63A TUNER(EUR) FM, AM, RDS(S/LAB) KST-MW104MV1-S63A 1 EA
...4 X701 HOX24576E150TF CRYSTAL 24.576MHZ 1 EA
...4 X702 HOX10000E220TF CRYSTAL(HC-49/S,ATS) 10MHz CL-22P 1 EA
Level
Ref. # Part Numbe
r
Description
Drawin
g
No
(
Value
)
Qt
y
UM
..3 COP12179C AVR2600 HDMI PCB ASS'
Y
1E
A
....5 BN15 CJP17GA193ZY WAFER, CARD CABLE (SMD) 1 EA
....5 CN55 CJP26GA226ZB DIP , SOCKET (26PIN, 2.54mm, SMD) 1 EA
....5 C601 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
....5 C602 CCUS1H223KC CAP , CHIP 0.022UF 50V K 1 EA
....5 C603 HCEC1CRV2101T CAP , CHIP ELECT (100UF/16V) 1 EA
....5 C604 CCSNA0J220B CAP , CHIP TANTAL
(
22uF/6.3V, Nin
g
Xia Xin
g
R
i
XRCA45 XXX M XXX AT 1 EA
....5 C605 CCSNA0J220B CAP , CHIP TANTAL
(
22uF/6.3V, Nin
g
Xia Xin
g
R
i
XRCA45 XXX M XXX AT 1 EA
....5 C606 CCSNA0J220B CAP , CHIP TANTAL
(
22uF/6.3V, Nin
g
Xia Xin
g
R
i
XRCA45 XXX M XXX AT 1 EA
....5 C607 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
....5 C608 CCUS1H223KC CAP , CHIP 0.022UF 50V K 1 EA
....5 C609 CCSNA1C100B CAP , CHIP TANTAL
(
10uF/16V, Nin
g
Xia Xin
g
Ri
)
XRCA45 XXX M XXX AT 1 EA
....5 C610 CCSNA1C100B CAP , CHIP TANTAL
(
10uF/16V, Nin
g
Xia Xin
g
Ri
)
XRCA45 XXX M XXX AT 1 EA
....5 C611 HCEC1CRV2101T CAP , CHIP ELECT (100UF/16V) 1 EA
....5 C612 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
....5 C613 CCUS1H102KC CAP , CHIP 1000PF 50V K 1 EA
....5 C614 CCUS1H103KC CAP , CHIP 0.01UF 50V K 1 EA
....5 C615 CCSNA0J220B CAP , CHIP TANTAL
(
22uF/6.3V, Nin
g
Xia Xin
g
R
i
XRCA45 XXX M XXX AT 1 EA
....5 C616 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
....5 C617 CCSNA0J220B CAP , CHIP TANTAL
(
22uF/6.3V, Nin
g
Xia Xin
g
R
i
XRCA45 XXX M XXX AT 1 EA
....5 C618 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
....5 C619 CCSNA0J220B CAP , CHIP TANTAL
(
22uF/6.3V, Nin
g
Xia Xin
g
R
i
XRCA45 XXX M XXX AT 1 EA
....5 C620 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
....5 C621 CCSNA0J220B CAP , CHIP TANTAL
(
22uF/6.3V, Nin
g
Xia Xin
g
R
i
XRCA45 XXX M XXX AT 1 EA
....5 C622 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
....5 C623 CCSNA0J220B CAP , CHIP TANTAL
(
22uF/6.3V, Nin
g
Xia Xin
g
R
i
XRCA45 XXX M XXX AT 1 EA
....5 C624 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
....5 C625 CCSNA0J220B CAP , CHIP TANTAL
(
22uF/6.3V, Nin
g
Xia Xin
g
R
i
XRCA45 XXX M XXX AT 1 EA
....5 C626 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
....5 C627 CCSNA0J220B CAP , CHIP TANTAL
(
22uF/6.3V, Nin
g
Xia Xin
g
R
i
XRCA45 XXX M XXX AT 1 EA
....5 C628 CCSNA1C100B CAP , CHIP TANTAL
(
10uF/16V, Nin
g
Xia Xin
g
Ri
)
XRCA45 XXX M XXX AT 1 EA
....5 C629 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
....5 C630 CCSNA0J220B CAP , CHIP TANTAL
(
22uF/6.3V, Nin
g
Xia Xin
g
R
i
XRCA45 XXX M XXX AT 1 EA
....5 C631 CCSNA0J220B CAP , CHIP TANTAL
(
22uF/6.3V, Nin
g
Xia Xin
g
R
i
XRCA45 XXX M XXX AT 1 EA
....5 C632 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
....5 C633 CCSNA0J220B CAP , CHIP TANTAL
(
22uF/6.3V, Nin
g
Xia Xin
g
R
i
XRCA45 XXX M XXX AT 1 EA
....5 C634 CCSNA0J220B CAP , CHIP TANTAL
(
22uF/6.3V, Nin
g
Xia Xin
g
R
i
XRCA45 XXX M XXX AT 1 EA
....5 C635 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
....5 C636 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
....5 C637 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
....5 C638 CCSNA1C100B CAP , CHIP TANTAL
(
10uF/16V, Nin
g
Xia Xin
g
Ri
)
XRCA45 XXX M XXX AT 1 EA
....5 C639 CCSNA0J220B CAP , CHIP TANTAL
(
22uF/6.3V, Nin
g
Xia Xin
g
R
i
XRCA45 XXX M XXX AT 1 EA
....5 C640 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
....5 C641 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
....5 C642 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
....5 C643 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
....5 C644 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
....5 C645 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
....5 C646 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
....5 C647 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
....5 C648 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
....5 C649 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
....5 C650 CCSNA1C100B CAP , CHIP TANTAL
(
10uF/16V, Nin
g
Xia Xin
g
Ri
)
XRCA45 XXX M XXX AT 1 EA
....5 C651 CCSNA0J220B CAP , CHIP TANTAL
(
22uF/6.3V, Nin
g
Xia Xin
g
R
i
XRCA45 XXX M XXX AT 1 EA
INPUT PCB ASS
Y
HDMI PCB ASS
Y
harman/kardon
AVR 360/230 Service Manual
Page 34 of 138
