Harman Kardon HKTS 20 - Page 43

Model name: HKTS200 SUB\230V for HKTS 20 and 30 systems
Component No. Description UOM Usage(pcs)
HSBA50431-3201 SCREW T4.0x2.85PxL20MM CED COATING PC 18
HSPA50352-4300 SCREW T4.0x2.85PxL30MM BLACK ZINC PC 4
HSBA70051-3120 GP SCREW STEEL BLACK ZINC PC 2
BRFA00049-0001 HKTS30-RUBBER FEET PC 4
BPVA00032-0001 AMP REAR COVER PC 1
GALA00198-0001 HKTS30-Logo AL PC 2
BPNA00008-0001 HKTS30-LED Cup PC 1
BPEA00006-0001 HKTS30-FOOT ABS HB PC 4
IVEA00168-0001 EVA BLACK PC 2
IVEA00168-0002 EVA BLACK PC 2
XBT090001-M000 BUTYL TAPE DIA 9.0 (2.5M/1R) M
XNL000003-0002 HOT MELT GLUE #1-286 D11.2mm KG
XNL500006-0001 PVC GLUE KG
XNJA21206-0011 STAPLE FOR C803/5/7/9 STEEL PLATE ZINC PC 4
DWT000012-0900 GP WIRE TIE GT-90M 90mm PC 2
XTP020300-0001 PE PROTECTIVE SHEET W300xT0.05mm RL
XNB000008-0001 THINNER MEK丁酮 18L/PAILFUL L
IVHA12002-0001 HKTS30-SEAL PE PAD PC 2
IVHA12002-0002 HKTS30-SEAL PE PAD PC 2
VOT050001-0010 BLUE LED CABLE 2P 350mm RED/BLACK PC 1
BPSA02012-0001 HKTS30-LED Cup Base PC 1
VWT502421-0300 GP WIRE TERM 2P 380mm RED/BLACK PC 1
XGLA00102-0001 704 BLACK SILICON GLUE 1pcs=90g PC
XAD050010-0001 DOUBLE SIDE TAPE W10mmxL50M/RL RL
IVEA00178-0001 EVA PAD PC 1
IVEA00152-0001 SPONGE L700*W30*T3.0 GRAY 单面背胶 PC 2
ASLA00340-0001 CABINET ASSY FOR HKTS30 PC 1
IVMA20001-0026 WADDING 杂布棉 PC 1
IVMA20001-0027 WADDING 杂布棉 PC 1
ASLA00340-0004 ACCESSORY ASSY FOR HKTS30 PC 1
IVAA02036-0001 PE BAG For WIRE PC 1
VRC202001-0010 RCA CABLE UL2547 24AWG BLACK/PURPLE PC 1
APKA00116-0001 PACKING ASSY FOR HKTS30 230V PC 1
ITFA30086-0001 HKTS30-TOP POLYFOAM PC 1
ITFA30086-0002 HKTS30-BOTTOM POLYFOAM PC 1
IVSA10047-0001 NON WEAVE BAG PC 1
ICCA00227-0001 HKTS30-CARTON BOX 230V PC 1
XAD030060-0001 OPP TAPE W60mmxL60YD 100RL/BOX RL
IVHA04022-0001 EPE PAD PC 1
XTP020020-0002 PE PROTECTIVE SHEET L100xW20xT0.05mm PC 2
YLBA18028-0001 BAR+SERIAL LABEL HKTS200 230V一式四份 SET 1
YLBA18029-0001 BAR+SERIAL AMP LABEL FOR HKTS200 230V PC 1
DOT040004-0001 DESICCANT 5G/BAG BAG 4
IVAA02034-0001 PE BAG PC 1
IVAA07021-0001 SOFT BAG PC 1
IVHA02016-0001 SOFT SHEET(单面附膜) PC 2
IVHA02016-M000 SOFT(单面附膜) M
FSBA2B080-0401 HKTS30 SUBWOOFER DRIVER PC 1
ASLA00341-0002 AMPLIFIER ASS'Y 230V HKTS30 PC 1
Harman Kardon
HKTS 20+30+60 Service Manual
Page 43 of 49
