IMPORTANT: THIS IS DATED INFORMATION. When requesting service or replacement
parts for your appliance please provide model number and serial number. All parts listed
in this manual may be ordered from an authorized dealer.
1 Cast Side Hinge Right 2-00-674048-2B
2 Mounting Frame Assembly 1-10-674043A
White, 1" w/Adhesive-1 Ply (Stove Frame) 10 FT 1-00-88100
3 All Thread .500-13 x 12, Frame Jacking Qty. 2 Req. 3-31-00949
4 Cast Side Hinge Left 2-00-674048-1B
5
Feeder Hopper Assembly - Height 20"
Pre 008240096 1-10-674115A
8240096 thru
008244667/Must also
order Switch retro t
Kit**
1-10-01781A
1-00-232108**
Post 00824467 1-10-01781A
Feeder Hopper Assembly - Height 22"
Pre 008240096 1-10-674112A
8240096 thru
008244667/Must also
order Switch retro t
Kit**
1-10-01782A
1-00-232108**
Post 008244667 1-10-01782A
Feeder Hopper Assembly - Height 24"
Pre 008240096 1-10-674063A
008240096 thru
008244667/ Must also
order Switch retro t
Kit**
1-10-01780A
1-00-232108**
Post 008244667 1-10-01780A
Gasket, Hopper Top 1-00-375501
Switch, Hopper 48" Post 008244667 3-20-232108
6 Pipe Stub for 4 in. Flex 1-10-674040W
Flue Pipe Insulation Wrap 3-44-674102
7 Pipe Stub Plate Gasket Pkg of 5 1-00-07384
8 Docking Gasket Red Silicon 3-44-06108
9 Combustion Blower 3-21-08639
Motor Blade, 4-3/4" Single Paddle 3-21-00661
Blower Mounting Screws Pkg of 100 1-00-53483208
Blower Mount Weldment 1-10-674006
10 Cast Top Bolt Plate 1-00-674109
11 Differential Switch 3-20-6866
12 Control Heat Shield 2-00-674061B
13 Control Board Mounting 1-10-674049L
Control Board Label 3-90-06655A
14 Spring Latch Qty. 2 Req. 3-31-00927
15 Steel Sleeve Bushing 1/2" OD x 3/4" 3-50-05230
Additional service parts on following page.
To Next Page
