3-90-00674R20_08/12
IMPORTANT: THIS IS DATED INFORMATION. When requesting service or replacement
parts for your appliance please provide model number and serial number. All parts listed
in this manual may be ordered from an authorized dealer.
16 Finished Body Weldment 1-89-674001W
17 Cast Center Medallion 3-00-674060
18 Cast Heat Exchanger CVR Qty. 2 Req. 3-00-674050
19 Flame Guide 3-00-03000
20 Hopper Lid Latch Kit Sold as kit only 1-00-674139
21 Cast Wing Center 4-00-674058P
22 Cast Hopper Lid 1-10-674059
Gasket, Hopper Top 1-00-375501
23 Hopper Lid Hinge Retainer Pkg of 4 1-00-674083
24 Cast Top 4-00-674055A
25 Cast Wing Left 4-00-674056P
26 Door Assembly 4-00-674053A
Door Latch 3-00-249119
Glass 3-40-674090
Glass Clip Pkg of 4 1-00-249140
Rope 3/16” Gasket w/PSA (Glass) 10 Ft 1-00-1186258229
Rope 3/8” Gasket
(Door) 30 Ft 1-00-00888
Wood Handle & Bolt Pkg of 2 1-00-00247
27 Cast Bottom Ashlip 3-00-674051P
28 Cast Side Panel Qty 2 Req. 4-00-674054P
29 Cast Wing Right 4-00-674057P
30 Burn Pot Weldment 1-10-00675
Igniter Element
3-20-677200
Pkg of 10 1-00-67200
Igniter Cradle, Holder, Flat bottom 3 Sets 1-00-06620
Ceramic Insert Gasket 3-44-724114
Cleanout Cover 2 sets 1-00-06623
Thumb Screw Pkg of 10 3-31-782108-10
31 Ash Pan 1-10-674030
32 Fan Protector Angle Qty 2 Req. 2-00-06114B
33 Distribution Blower 3-21-47120
34 Hinge Plate Qty 2 Req. 3-00-674047
35 Flue Box Cleanout Cover 2-00-674009B
36 Burn Pot /Tail Pipe Gasket Pkg of 5 1-00-07381
37
Feeder Assembly
Pre 008240096 1-10-01679A
38 Post 008240096 1-10-01779A
Additional service parts on following page.
