TR01526_A
ID
• Nama Model: HK OMNI 10+
• Transduser:1x90mmwoofer,1x35mmtweeter
• Nilai daya: 1 x 25W untuk woofer; 1 x 25W untuk tweeter
• Respons frekuensi: 52~20kHz (-6dB)
• Rasio sinyal-ke-bunyi: >80dB
• Input koneksi: Bluetooth®, Aux-in, Wi-Fi, 10/100 Mbps Ethernet port
• Dimensi (W x D x H): 181mm x 159mm x 166mm
• Berat: 1333g
• Catu daya: 19VDC, 3.0A
• Rentang frekuensi pemancar Bluetooth®: 2402 − 2480MHz
• Daya pemancar Bluetooth®: 0-4dBm
• Modulasi pemancar Bluetooth®: GFSK, π/4 DQPSK, 8DPSK
• Rentang frekuensi pemancar 2.4G Wi-Fi: 2412 − 2472MHz
(2.4GHz ISM Band, USA 11 Kanal, Eropa dan 13 Kanal lain)
• Daya pemancar 2.4G Wi-Fi: <20dBm (EIRP)
• Modulasi 2.4G Wi-Fi: OFDM, DSSS, DBPSK, DQPSK, CCK, 16QAM, 64QAM
• Kompatibilitas jaringan 2.4G Wi-Fi: IEEE 802.11b/g/n
• Daya pemancar 5G Wi-Fi: <18.5dBm
• Modulasi 5G Wi-Fi: OFDM, DSSS, DBPSK, DQPSK, CCK, 16QAM,
64QAM, 256QAM
• Kompatibilitas jaringan 5G Wi-Fi: IEEE 802.11ac
• Network standby power<3W
FPO
FPO
CHS CHT
• 型號名稱：HK OMNI 10+
• 轉換器：1x90mm 低音喇叭, 1x35mm 高音喇叭
• 額定功率：低音喇叭, 1x25W；高音喇叭, 1x25W
• 頻率回應：52~20kHz (-6dB)
• 雜訊比：>80dB
• 輸入連接：Bluetooth®、Aux 輸入、Wi-Fi、
10/100 Mbps Ethernet port
• 尺寸（寬 x 深 x 高）：181mm x 159mm x 166mm
• 重量：1333 克
• 電源：19VDC，3.0A
• Bluetooth® 發射機頻率範圍：2402 − 2480MHz
• Bluetooth® 發射機功率：0-4dBm
• Bluetooth® 發射機調變：GFSK、π/4 DQPSK、8DPSK
• 2.4G Wi-Fi 發射機頻率範圍：2412 − 2472MHz（2.4GHz ISM 頻帶、
美國 11 個頻道、歐洲和其他 13 個頻道）
• 2.4G Wi-Fi 發射機功率：<20dBm (EIRP)
• 2.4G Wi-Fi 調變：OFDM、DSSS、DBPSK、DQPSK、CCK、
16QAM、64QAM
• 2.4G Wi-Fi 網路相容性：IEEE 802.11b/g/n
• 5G Wi-Fi 發射機功率：<18.5dBm
• 5G Wi-Fi 調變：OFDM、DSSS、DBPSK、DQPSK、CCK、
16QAM、64QAM, 256QAM
• 5G Wi-Fi 網路相容性：IEEE 802.11ac
• Network standby power<3W
• 型号名称：HK OMNI 10+
• 换能器：1 个 90mm 低音扬声器, 1 个 35mm 高音扬声器
• 额定功率：低音扬声器, 1 个, 25W；高音扬声器, 1 个, 25W
• 频率响应：52~20kHz (-6dB)
• 信噪比：>80dB
• 输入连接：Bluetooth®、辅助输入、Wi-Fi、10/100 Mbps Ethernet port
• 尺寸（宽 x 长 x 高）：181mm x 159mm x 166mm
• 重量：1333g
• 电源：19VDC，3.0A
• Bluetooth® 发射器频率范围：2402 − 2480MHz
• Bluetooth® 发射器功率：0-4dBm
• Bluetooth® 发射器调制：GFSK, π/4 DQPSK, 8DPSK
• 2.4G Wi-Fi 发射器频率范围：2412 − 2472MHz（2.4GHz ISM 频带,
美国 11 个频道, 欧洲和其他国家/地区 13 个频道）
• 2.4G Wi-Fi 发射器功率：<20dBm (EIRP)
• 2.4G Wi-Fi 调制：OFDM, DSSS, DBPSK, DQPSK, CCK, 16QAM, 64QAM
• 2.4G Wi-Fi 网络兼容性：IEEE 802.11b/g/n
• 5G Wi-Fi 发射器功率：<18.5dBm
• 5G Wi-Fi 调制：OFDM, DSSS, DBPSK, DQPSK, CCK, 16QAM,
64QAM, 256QAM
• 5G Wi-Fi 网络兼容性：IEEE 802.11ac
• Network standby power<3W
FPO
FPO
FPO
FPO
JP KO
• 모델명: HK OMNI 10+
• 변환기: 1 x 90mm 우퍼, 1 x 35mm 트위터
• 정격 전력: 우퍼용 1 x 25W, 트위터용1x25W
• 주파수 응답: 52~20kHz (-6dB)
• 신호 대 잡음비:>80dB
• 입력 연결: 블루투스®, 보조 입력, Wi-Fi, 10/100 Mbps Ethernet port
• 치수(너비 x 깊이 x 높이): 181mm x 159mm x 166mm
• 중량: 1333g
• 전원 공급 장치: 19VDC, 3.0A
• 블루투스® 송신기 주파수 범위: 2402 ~ 2480MHz
• 블루투스® 송신기 출력
: 0-4dBm
• 블루투스® 송신기 변조: GFSK, π/4 DQPSK, 8DPSK
• 2.4G Wi-Fi 송신기 주파수 범위: 2412 ~ 2472MHz (2.4GHz ISM 밴드,
미국 11 채널, 유럽 및 기타 지역 13 채널)
• 2.4G Wi-Fi 송신기 출력: <20dBm(EIRP)
• 2.4G Wi-Fi 변조: OFDM, DSSS, DBPSK, DQPSK, CCK, 16QAM, 64QAM
• 2.4G Wi-Fi 네트워크 호환성: IEEE 802.11b/g/n
• 5G Wi-Fi 송신기 출력: <18.5dBm
• 5G Wi-Fi 변조: OFDM, DSSS, DBPSK, DQPSK, CCK, 16QAM,
64QAM, 256QAM
• 5G Wi-Fi 네트워크 호환성: IEEE 802.11ac
• Network standby power<3W
• モデル名：HK OMNI 10+
• トランスデューサー：1 x 90mmウーファー、1 x 35mmツイーター
• 定格出力：ウーファー用 1 x 25W;ツイーター用 1 x 25W
• 周波数特性：52〜20kHz (-6dB)
• S/N比：80dB以下
• 入力接続：Bluetooth®、Aux端子、Wi-Fi、
10/100 Mbps Ethernet port
• 寸法（幅x奥行x高さ）：181mm x 159mm x 166mm
• 重量：1333g
• 電源：直流19V、3.0A
• Bluetooth®対応トランスミッター周波数帯域：2402〜2480MHz
• Bluetooth®対応トランスミッター出力：0-4dBm以上
• Bluetooth®対応トランスミッター変調：GFSK、π/4 DQPSK、8DPSK
• 2.4G WiFiトランスミッター周波数帯域：2412〜2472MHz
(2.4GHz ISMバンド、USA 11チャンネル、
Europeとその他の地域 13チャンネル )
• 2.4G WiFiトランスミッター出 力：20dBm(EIRP)以上
• 2.4G WiFi変調：OFDM、DSSS、DBPSK、DQPSK、CCK、16QAM、64QAM
• 2.4G WiFiネットワークへの互換性：IEEE 802.11b/g/n
• 5G WiFiトランスミッター出力：18.5dBm以上
• 5G WiFi変調：OFDM、DSSS、DBPSK、DQPSK、CCK、16QAM、
64QAM, 256QAM
• 5G WiFiネットワークへの互換性：IEEE 802.11ac
• Network standby power<3W
FPO
FPO
FPO
FPO
SV DA
• Modelnavn: HK OMNI 10+
• Transducere: 1 x 90 mm woofer, 1 x 35 mm tweeter
• Nominel effekt: 1 x 25 W for woofer; 1 x 25 W for tweeter
• Frekvensområde: 52 ~ 20 kHz (-6 dB)
• Signal til støj-forhold: >80 dB
• Indgangstilslutninger: Bluetooth®, Aux-indgang, Wi-Fi, 10/100 Mbps
Ethernet port
• M
ål (B x D x H): 181mm x 159mm x 166mm
• Vægt: 1,333g
• Strømforsyning: 19 V DC, 3.0A
• Frekvensområde for Bluetooth®-sender: 2402 − 2480 MHz
• Bluetooth®-sendereffekt: 0-4 dBm
• Bluetooth®-sendemodulation: GFSK, π/4 DQPSK, 8DPSK
• Frekvensområde for 2,4 G Wi-Fi-sender: 2.412 − 2.472 MHz
(2,4 GHz ISM-bånd, USA:11 kanaler, Europa og andre lande: 13 kanaler)
• 2,4 G Wi-Fi-sendereffekt: <20 dBm (EIRP)
• 2,4 G Wi-Fi-modulation: OFDM, DSSS, DBPSK, DQPSK, CCK,
16QAM, 64QAM
• 2,4 G Wi-Fi-netværkskompatibilit
et: IEEE 802.11b/g/n
• 5 G Wi-Fi-sendereffekt: <18,5 dBm
• 5GWi-F
i-modulation: OFDM, DSSS, DBPSK, DQPSK, CCK,
16QAM, 64QAM, 256QAM
• 5 G Wi-Fi-netværkskompatibilitet: IEEE 802.11ac
• Network standby power<3W
• Modellnamn: HK OMNI 10+
• Högtalarelement: 1 x 90 mm woofer, 1 x 35 mm diskant
• Klassad effekt: 1 x 25 W för woofer; 1 x 25 W för diskant
• Frekvensomfång: 52 Hz~20 kHz (-6 dB)
• Signal-brus-förhållande: >80 dB
• Ingångar: Bluetooth®, Aux-in, Wi-Fi, 10/100 Mbps Ethernet port
•
Dimensioner (B x D x H): 181 x 159 x 166 mm
• Vikt: 1 333 g
• Strömförsörjning: 19 V DC, 3,0 A
• Bluetooth®-sändarens frekvensomfång: 2 402 − 2 480 GHz
• Bluetooth®-sändarens effekt: 0-4 dBm
• Bluetooth®-sändarens modulering: GFSK, π/4 DQPSK, 8DPSK
• 2,4 G Wi-Fi-sändarens frekvensomfång: 2 412 MHz~2 472 MHz
(2,4 GHz ISM-band, USA 11-kanaler, Europa 13-kanaler)
• 2,4 G Wi-Fi-sändarens effekt: < 20 dBm (ERIP)
• 2,4 G Wi-Fi-modulering: OFDM, DSSS, DBPSK, DQPSK, CCK,
16QAM, 64QAM
• 2,4 G Wi-Fi nätverkskompatibilit
et: IEEE 802.11b/g/n
• 5 G Wi-Fi-sändarens effekt: < 18.5 dBm
• 5 G Wi-Fi-modulering: OFDM, DSSS, DBPSK, DQPSK, CCK,
16QAM, 64QAM, 256QAM
• 5 G Wi-Fi nätverkskompatibilitet: IEEE 802.11ac
• Network standby power<3W
FPO
FPO
FPO
FPO
0560
The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by HARMAN International
Industries, Incorporated is under license. Other trademarks and trade names are those of their respective owners.
This Mark Certifies that this product is compliant with the BLACKFIRE ALLIANCE Standard.
Please refer to WWW.BLACKFIREALLIANCE.COM for more information.
BLACKFIRE RESEARCH™ is a Registered Trademark (No. 3,898,359) of BLACKFIRE RESEARCH CORP.
All rights reserved.
The Wi-Fi CERTIFIED Logo is a certification mark of the Wi-Fi Alliance.
The Wi-Fi Protected Setup Identifier Mark is a mark of the Wi-Fi Alliance.
“Made for iPod,”“Made for iPhone,”and“Made for iPad”mean that an electronic accessory has been designed to connect specifically to iPod, iPhone,
or iPad, respectively, and has been certified by the developer to meet Apple performance standards. Apple is not responsible for the operation of
this device or its compliance with safety and regulatory standards. Please note that the use of this accessory with iPod, iPhone, or iPad may affect
wireless performance.
AirPlay, iPad, iPhone, iPod, iPod classic, iPod nano, iPod touch, and Retina are trademarks of Apple Inc., registered in the U.S. and other countries. iPad
Air, iPad mini, and Lightning are trademarks of Apple Inc. In Japan,The trademark “iPhone” is used with a license from Aiphone K.K
Торговая марка : harman/kardon
Назначение товара : АКТИВНАЯ АКУСТИЧЕСКАЯ СИСТЕМА
Изготовитель : ХАРМАН ИНТЕРНЕШНЛ ИНДАСТРИЗ ИНКОРПОРЕЙТЕД, США, 06901 КОННЕКТИКУТ,
г.СТЭМФОРД, АТЛАНТИК СТРИТ 400, ОФИС 1500
Страна происхождения : Китай
Импортер в Россию : OOO “ХАРМАН РУС СиАйЭс“, РОССИЯ, 127018, г.МОСКВА, УЛ. ДВИНЦЕВ, Д.12, КОРПУС 1
Гарантийный период : 1 год
Информация о
сервисных центрах : www.harman.com/ru тел. +7-800-700-0467
Срок службы : 5 лет
Срок хранения : не ограничен
Условия хранения : Cтандартные при нормальных значениях климатических факторов внешней среды
Номер документа
соответствия : Товар сертифицирован
Дата производства : Дата изготовления устройства определяется по двум буквенным обозначениям из второй группы
символов серийного номера изделия, следующих после разделительного знака «-». Кодировка
соответствует порядку букв латинского алфавита, начиная с января 2010 года: 000000-MY0000000,
где «M» - месяц производства (А - январь, B - февраль, C - март и т.д.) и «Y» - год производства
(A - 2010, B - 2011, C - 2012 и т.д.).
ES PT
• Nome do modelo: HK OMNI 10+
• Transdutores: 1 woofer de 90 mm e 1 tweeter de 35 mm
• Potêncianominal:1x25Wpara owoofere1x25Wpara otweeter
• Resposta de frequência: 52~20 kHz (-6 dB)
• Razão sinal-ruído: >80 dB
• Conexões de entrada: Bluetooth®, Aux-in, Wi-Fi, 10/100 Mbps Ethernet port
• Dimensões (L x P x A): 181 mm x 159 mm x 166 mm
• Peso: 1333 g
• Font
e de alimentação: 19 VDC, 3,0 A
• Intervalo de fr
equência de transmissão Bluetooth®: 2402 − 2480 MHz
• Potência de transmissão Bluetooth®: 0-4 dBm
• Modulação da transmissão Bluetooth®: GFSK, π/4 DQPSK, 8DPSK
• Intervalo de frequência do transmissor Wi-Fi 2,4 G: 2412 − 2472 MHz
(banda ISM 2,4 GHz, 11 canais padrão EUA, Europa e outros 13 canais)
• Potência do transmissor Wi-Fi 2,4 G: <20 dBm (EIRP)
• Modulação Wi-Fi 2,4 G: OFDM, DSSS, DBPSK, DQPSK, CCK,
16QAM, 64QAM
• C
ompatibilidade de rede Wi-Fi 2,4 G: IEEE 802.11b/g/n
• Potência do transmissor Wi-Fi 5 G: <18,5 dBm
• Modulação Wi-Fi 5 G: OFDM, DSSS, DBPSK, DQPSK, CCK,
16QAM, 64QAM, 256QAM
• C
ompatibilidade de rede Wi-Fi 5 G: IEEE 802.11ac
• Network standby power<3W
• Nombre del modelo: HK OMNI 10+
• Transductores: 1 woofer x 90 mm, 1 altavo
z de agudos x 35 mm
• Potencia de entrada nominal: 1 woofer x 25 W;
1 altavoz de agudos x 25 W
• Intervalo de frecuencias: 52 ~ 20 kHz (-6 dB)
• Relación señal-ruido: >80 dB
• Conexiones de entrada: Bluetooth®, Aux-in, Wi-Fi, 10/100 Mbps
Ethernet port
• Dimensiones (Ancho x Alto x Pr
ofundidad): 181mm x 159mm x 166mm
• Peso: 1.333g
• Alimentación: 19VDC, 3,0A
• Alcance de frecuencia del transmisor Bluetooth®: 2402 − 2480 MHz
• Potencia del transmisor Bluetooth®: 0-4 dBm
• Modulación del transmisor Bluetooth®: GFSK, π/4 DQPSK, 8DPSK
• Intervalo de frecuencias del transmisor Wi-Fi 2.4G: 2412 − 2472 MHz
(Banda ISM 2,4 GHz, 11 canales en USA, 13 canales en Europa y otros)
• Potencia del transmisor Wi-Fi 2.4G: <20 dBm (EIRP)
• Modulación Wi-Fi 2.4G: OFDM, DSSS, DBPSK, DQPSK, CCK,
16QAM, 64QAM
• Compatibilidad de red Wi-Fi 2.4G: IEEE 802.11b/g/n
• Potencia del transmisor Wi-Fi 5G: <18.5 dBm
• Modulación Wi-Fi 5G: OFDM, DSSS, DBPSK, DQPSK, CCK, 16QAM, 64QAM,
256QAM
• Compatibilidad de red Wi-Fi 5G: IEEE 802.11ac
• Network standby power<3W
FPO
FPO
FPO FPO
DE IT
• Nome Modello: HK OMNI 10+
• Trasduttori:1x90mmwoofer,1x35mmtweeter
• Pot
enza nominale: 1 x 25W woofer; 1 x 25W tweeter
• Risposta in frequenza: 52~20kHz (-6dB)
• Rapporto segnale-rumore: >80dB
• Connessioni in ingresso: Bluetooth®, Aux-in, Wi-Fi, 10/100 Mbps
Ethernet port
• Dimensioni (L x P x A): 181mm x 159mm x 166mm
• Peso: 1333g
• Alimentazione: 19VDC, 3.0A
• Gamma di frequenza trasmettitore Bluetooth®: 2402 − 2480MHz
• Potenza trasmettitore Bluetooth®: 0-4dBm
• Modulazione trasmettitore Bluetooth®: GFSK, π/4 DQPSK, 8DPSK
• Gamma di frequenza trasmettitore Wi-Fi 2.4G: 2412 − 2472MHz
(Banda 2.4GHz ISM, USA 11 Canali, Europa ed altri 13 Canali)
• Potenza trasmettitore Wi-Fi 2.4G: <20dBm (EIRP)
• Modulazione Wi-Fi 2.4G: OFDM, DSSS, DBPSK
,DQPSK,CCK,
16QAM, 64QAM
• Compatibilità network Wi-Fi 2.4G: IEEE 802.11b/g/n
• Potenza trasmettitore Wi-Fi 5G: <18.5dBm
• Modulazione Wi-Fi 5G: OFDM, DSSS, DBPSK
,DQPSK,CCK,
16QAM, 64QAM, 256QAM
• Compatibilità network Wi-Fi 5G: IEEE 802.11ac
• Network standby power<3W
• Modellbezeichnung: HK OMNI 10+
• Signalumwandler: 1 x 90mm Tieftöner, 1 x 35mm Hochtöner
• Nennleistung: 1 x 25W für den Tieftöner, 1 x 25W für den Hochtöner
• Frequenzbereich: 52~20kHz (-6dB)
• R
auschabstand: >80dB
• Eingangsverbindungen: Bluetooth®, Aux-in, WLAN, 10/100 Mbps
Ethernet port
• Abmessungen (B x
T x H): 181mm x 159mm x 166mm
• Gewicht: 1333g
• Energieversorgung: 19 VDC, 3,0A
• Frequenzbereich für die Bluetooth®-Übertragung: 2402 – 2480MHz
• Bluetooth®-Übertragungsleistung: 0-4 dBm
• Bluetooth®-Übertragungsmodulation: GFSK, π/4 DQPSK, 8DPSK
• 2.4G WLAN-Übertragungsfrequenzbereich: 2412 − 2472MHz
(2.4GHz ISM-Band, USA 11 Kanäle, Europa und andere Länder 13 Kanäle)
• 2.4G WLAN-Über
tragungsleistung: <20dBm (EIRP)
• 2.4G WLAN-Modulation: OFDM, DSSS, DBPSK, DQPSK, CCK,
16QAM, 64QAM
• 2.4G WLAN-Netzwerkkompatibilität: IEEE 802.11b/g/n
• 5G WLAN-Übertragungsleistung: <18.5dBm
• 5G WLAN-M
odulation: OFDM, DSSS, DBPSK, DQPSK, CCK,
16QAM, 64QAM, 256QAM
• 5G WLAN-Netzwerkkompatibilität: IEEE 802.11ac
• Network standby power<3W
FPOFPO
FPO FPO
NL NO
• Modellnavn: HK OMNI 10+
• Signalomformere: 1 x 90 mm woofer, 1 x 35 mm tweeter
• Nominelleffekt:1x25Wforwoofer;1x25Wfortweeter
• Frekvensrespons: 52~20 kHz (-6 dB)
• Signal-til-lyd-ratio: >80 dB
• Innganger: Bluetooth®, Aux-in, Wi-Fi, 10/100 Mbps Ethernet port
•
Dimensjoner (L x B x H): 181mm x 159mm x 166mm
• Vekt: 1,333g
• Strømforsyning: 19 VDC, 3,0A
• Frekvensområde for Bluetooth®-sender: 2402 − 2480 MHz
• Strøm for Bluetooth®-sender: 0-4 dBm
• Modulasjon for Bluetooth®-sender: GFSK, π/4 DQPSK, 8DPSK
• 2,4G WiFi-frekvensområde for sender: 2412 – 2472 MHz (2,4 GHz
ISM-bånd, USA 11 kanaler, Europa og andre 13 kanaler)
• Strøm for 2,4 G Wi-Fi-sender: <20 dBm (EIRP)
• 2,4 G Wi-Fi-modulasjon: OFDM, DSSS, DBPSK, DQPSK, CCK,
16QAM, 64QAM
• 2,4 G Wi-Fi-nettverkskompatibilitet: IEEE 802.11 b/g/n
• Strøm for 5 G Wi-Fi-sender: <18.5 dBm
• 5GWi-F
i-modulasjon: OFDM, DSSS, DBPSK, DQPSK, CCK,
16QAM, 64QAM, 256QAM
• 5 G Wi-Fi-nettverkskompatibilitet: IEEE 802.11 ac
• Network standby power<3W
• M
odelnaam: HK OMNI 10+
• Transducers: 1 x 90mm woofer, 1 x 35mm tweeter
• Nominaal vermogen: 1 x 25W voor woofer; 1 x 25W voor tweeter
• Frequentiebereik: 52~20kHz (-6dB)
• Signaal-ruis-verhouding: >80dB
• Ingangen: Bluetooth®, Aux-in, Wi-Fi, 10/100 Mbps Ethernet port
• Afmetingen (B x D x H): 181mm x 159mm x 166mm
• Gewicht: 1.333g
• Voeding: 19VDC, 3.0A
• Bluetooth® zendfrequentiebereik: 2402 − 2480MHz
• Bluetooth® zendvermogen: 0-4dBm
• Bluetooth® zendermodulatie: GFSK, π/4 DQPSK, 8DPSK
• 2.4G Wi-Fi zendfrequentiebereik: 2412 − 2472MHz (2.4GHz ISM Band,
USA 11 kanalen, Europa en andere 13 kanalen)
• 2.4G Wi-Fi zendvermogen: <20dBm (EIRP)
• 2.4G Wi-Fi modulatie: OFDM, DSSS, DBPSK, DQPSK, CCK,
16QAM, 64QAM
• 2.4G Wi-Fi netwerk compatibiliteit: IEEE 802.11b/g/n
• 5G Wi-Fi zendvermogen: <18.5dBm
• 5G Wi-Fi modulatie: OFDM, DSSS, DBPSK, DQPSK, CCK,
16QAM, 64QAM, 256QAM
• 5G Wi-Fi netwerk compatibiliteit: IEEE 802.11ac
• Network standby power<3W
FPOFPO
FPO FPO
FI RU
• Название модели: HK OMNI 10+
• Преобразователи: 1 низкочастотный динамик 90 мм,
1 высокочастотный динамик 35 мм
• Номинальная мощность: 1 x 25 Вт для низкочастотного динамика;
1 x 25 Вт для высокочастотного динамика
• Частотная характеристика: 52~20 КГц (-6 дБ)
• Отношение "сигнал-шум": >80 дБ
• Входные соединения: Bluetooth®, Aux-in, Wi-Fi, 10/100 Mbps Ethernet port
• Габарит
ы(ДxШxВ):181ммx159ммx166мм
• Вес: 1333 г
• Источник питания: 19 В постоянного тока, 3,0A
• Частотный диапазон передатчика Bluetooth®: 2402 – 2480 МГц
• Мощность передатчика Bluetooth®: макс. 0-4 дБ/мВт
• Модуляция передатчика Bluetooth®: гаусс. част. модул., π/4 относ.
квадрат. фаз. модул., относ. восьмер. фаз. модул.
• Частотный диапазон передатчика 2.4G Wi-Fi: 2412 − 2472 МГц
(2,4 ГГц диапазона ISM, США 11 каналов, Европа и другие
страны 13 каналов)
• Мощность передатчика 2.4G Wi-Fi: <20 дБ/мВт (ERIP)
• Модуляция 2.4G Wi-Fi: OFDM, DSSS, DBPSK, DQPSK, CCK,
16QAM, 64QAM
• Сетевой стандарт 2.4G Wi-Fi: IEEE 802.11b/g/n
• Мощность передатчика 5G Wi-Fi: <18.5 дБ/мВт
• Модуляция 5G Wi-Fi: OFDM, DSSS, DBPSK, DQPSK, CCK, 16QAM,
64QAM, 256QAM
• Сетевой стандарт 5G Wi-Fi: IEEE 802.11ac
• Network standby power<3W
• Mallin nimi: HK OMNI 10+
• Muuntimet: 1 x 90 mm:n alibassokaiutin, 1 x 35 mm:n diskanttikaiutin
• Nimellisottoteho: 1 x 25 W alibassokaiuttimelle; 1 x 25 W diskanttikaiuttimelle
• Taajuusvaste: 52~20 kHz (-6 dB)
• Signaali-k
ohina-suhde: >80 dB
• Tuloliitännät: Bluetooth®, Aux-tulo, Wi-Fi, 10/100 Mbps Ethernet port
• Mitat (L x K x H): 181 mm x 159 mm x 166 mm
• Paino: 1 333 g
• Virransyöttö: 19 VDC, 3,0 A
• Bluetooth®-lähettimen taajuusalue: 2402 − 2480 MHz
• Bluetooth®-lähettimen teho: 0-4 dBm
• Bluetooth®-lähettimen modulaatio: GFSK, π/4 DQPSK, 8 DPSK
• 2,4 G Wi-Fi-lähettimen taajuusalue: 2412 − 2472 MHz (2,4 GHz ISM-kaista,
Yhdysvallat 11 kanavaa, Eurooppa ja muut 13 kanavaa)
• 2,4 G Wi-Fi-lähettimen teho: < 20 dBm (EIRP)
• 2,4 G Wi-Fi-modulaatio: OFDM, DSSS, DBPSK, DQPSK, CCK,
16QAM, 64QAM
• 2,4 G Wi-Fi-verkon yhteensopivuus: IEEE 802.11b/g/n
• 5 G Wi-Fi-lähettimen teho: < 18.5 dBm
• 5 G Wi-Fi-modulaatio: OFDM, DSSS, DBPSK, DQPSK, CCK,
16QAM, 64QAM, 256QAM
• 5 G Wi-Fi-verkon yhteensopivuus: IEEE 802.11ac
• Network standby power<3W
FPO
FPO
FPO
FPO
IC Caution:
User should also be advised that:
(i) the device for operation in the band 5150 - 5250 MHz is only for indoor use to reduce the potential for harmful interference to co-channel mobile satellite systems;
(ii) the maximum antenna gain permitted for devices in the bands 5250 - 5350 MHz and 5470 - 5725 MHz shall comply with the e.i.r.p. limit: and
(iii) the maximum antenna gain permitted for devices in the band 5725 - 5825 MHz shall comply with the e.i.r.p. limits specified for point-to-point and non point-to-point operation as
appropriate.
(iv) Users should also be advised that high-power radars are allocated as primary users (i.e. priority users) of the bands 5250 - 5350 MHz and 5650 - 5850 MHz and that these radars could cause
interference and/or damage to LE-LAN devices.
Les utilisateurs devraient aussi être avisés que
(i) les dispositifs fonctionnant dans la bande 5150-5250 MHz sont réservés uniquement pour une utilisation à l’intérieur afin de réduire les risques de brouillage préjudiciable aux systèmes de
satellites mobiles utilisant les mêmes canaux;
(ii) le gain maximal d’antenne permis pour les dispositifs utilisant les bandes 5 250-5 350 MHz et 5 470-5 725 MHz doit se conformer à la limite de p.i.r.e.;
(iii) le gain maximal d’antenne permis (pour les dispositifs utilisant la bande 5 725-5 825 MHz) doit se conformer à la limite de p.i.r.e. spécifiée pour l’exploitation point à point et non point à
point, selon le cas.De plus, les utilisateurs de radars de haute puissance sont désignés utilisateurs principaux (c.-à-d., qu’ils ont la priorité) pour les bandes 5 250-5 350 MHz et 5 650-5 850 MHz et
que ces radars pourrai ent causer du brouillage et/ou des dommages aux dispositifs LAN-EL.
Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
º Reorient or relocate the receiving antenna.
º Increase the separation between the equipment and receiver.
º Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
º Consult the dealer or an experienced radio/TV technician for help.
High power radars are allocated as primary users of the 5.25 to 5.35 GHz and 5.65 to 5.85 GHz bands. These radar stations can cause interference with and/or damage this device. No
configuration controls are provided for this wireless equipment allowing any change in the frequency of operations outside the FCC grant of authorization for US operation according to Part
15.407 of the FCC rules.
High power radars are allocated as primary users of the 5.25 to 5.35 GHz and 5.65 to 5.85 GHz bands. These radar stations can cause interference with and/or damage this device. No
configuration controls are provided for this wireless equipment allowing any change in the frequency of operations outside the FCC grant of authorization for US operation according to Part
15.407 of the FCC rules.
“FCC RF Radiation Exposure Statement Caution: To maintain compliance with the FCC’s RF exposure guidelines, place the product at least 20cm from nearby persons.”
Use Restriction Attention In France, operation is limited to indoor use within the band 5150-5350 MHz.
해당무선설비는전파혼신가능성이있으므로인명안전과관련된서비스는할수없음
To Next Page
Loading...
Need help?
General
