Harman JBL ARENA SUB100P User Manual

PartNumber Description
BB000185 Amplifier(switch&cord)ArenaSUB100P
SP100028 wooferArenaSUB100P
02340057 woofertrimringArenaSUB100P
02160012 porttube
01400073 plasticlogoArenaSUB100P
02620108 SiliconerubberfeetArenaSUB100P
7140030 insertnut(Feetinsert)'M6*25mmArenaSUB100P
07020076 selfͲtappingscrew'ˇ4*20mmArenaSUB100P
07020080 selfͲtappingscrew'ˇ4*25mmArenaSUB100P
07140028 steelspikeArenaSUB100P
22010356 ManualArenaSUB100P
22010357 safety
manualArenaSUB100P
22020031 warrantycardEMEAArenaSUB100P
22020032 ChinaROHScard
23010009 PEbagformanualArenaSUB100P
23010011 PEbagforaccessoriesArenaSUB100P
23010504 EPEbagArenaSUB100P
23020183 topstyrofoamcoverArenaSUB100P
23020184 bottomstyrofoamcoverArenaSUB100P
23030592 CartonBoxArenaSUB100PArenaSUB100P
16070019 powercordUSL=1.83mblack
16070029 powercordEUL=1.83mblackArenaSUB100P
16070075 powercordChinaL=1.83mblack
16070063 powercordJapanL=1.83mblack
19020016 Fuse2A/250V5*20mm
14040183 ICOB2269CCPSOP8SUB100P
14040072 ICFAN431ATOͲ92SUB100P
60020002 ICPhotocouplerEL817CDIP4SUB100P
11200018 Thermister100KɏNTC±5λSUB100P
13030099 TransformerEC35100WHiͲFREQSUB100P
14010167 MOSCS10N60&FDPF10N60SUB100P
18020019 BridgerectifierRS406L&KBL406H=10mmL=4mm
14040203 ICMC33172SOP8SUB100P
14040097 ICNJM4558SOP8JRCSUB100P
40190070 RCAconnector
RCAͲ2081PSUB100P
K0100752 FrontPanelPCBArenaSUB100P
K0100796 AmplifierPCBArenaSUB100P
19070001 FuseholderArenaSUB100P
12030010 PowerSwitchArenaSUB100P
20210005 KnobArenaSUB100P
40010007 MainPowerConnectorArenaSUB100P
02090042 FrontAssemblyArenaSUB100P
ArenaSUB100P General PartsList

Harman JBL ARENA SUB100P Specifications

General

Brand	Harman
Model	JBL ARENA SUB100P
Category	Subwoofer
Language	English
