JBL CLUB704 SPARE PARTS LIST
Pos. No.
P/N Description Usage
1 MP0101000046 LOGO 20.1*16.1*4.2MM CLUB704 1
2 ZS0301100039 DECORATIVE SHEET PC CLUB704 1
7 88LE03200402 LED PCBA CLUB704 1
11 88AM03200819 MAIN PCBA CLUB704/REF704A 1
16 MK0101000768 RCA COVER CLUB704 1
17 88FA03200421 PRE AMP PCBA CLUB704/REF704A 1
29 SG0101000072 AC SOCKET ABS CLUB704 1
30 SG0101000071 SPEAKER JACK BRACKET ABS CLUB704 2
35 MK0101400707 FUSE COVER 2PIN 24*24*0.6 CLUB704/REF704A 1
C35P, C36P 020513000218 CAP. 3300uF/35V ±20% 105Ԩ CLUB704/REF704A 2
C5P, C6P, C57P,
C58P
020513000385 CAP. 3300uF/25V ±20% 105Ԩ CLUB704/REF704A 4
CN3 130223000015 CONNECTOR P2.0MM 3PIN CLUB704/REF704A 1
D7P, D9P 040403000041 Bridge F16C20CT TO-263 CLUB704/REF704A 2
D8P, D10P 040403000040 Bridge F16A20CT TO-263 CLUB704/REF704A 2
F1 120103000008 FUSE Socket DIP 2P CLUB704/REF704A 1
JK1 120303000031 HEADPHONE JACK CLUB704/REF704A 1
JK2 121103000003 NETWORK SOCKET 8P CLUB704/REF704A 1
JK3A,JK3B,JK3C,JK
120903000132 SPEAKER JACK CLUB704/REF704A 9
JK5A,JK5B 120903000131 POWER JACK CLUB704/REF704A 2
L1P 030123000121 IND. 2.5mH ф0.7*8P*10.5Ts CLUB704/REF704A 1
Q107, Q207, Q307,
050203000168 Transistor MPSA13 TO-92 CLUB704/REF704A 4
Q108, Q208, Q308,
Q408, Q16P
050203000116 Transistor 2SD669A NPN CLUB704/REF704A 5
Q109, Q209, Q309,
050103000083 Transistor 2SB649A PNP CLUB704/REF704A 5
Q110, Q210,Q310,
050203000174 Transistor TIP35C TO-3P NPN CLUB704/REF704A 4
Q111, Q211,Q311,
050203000175 Transistor TIP36C TO-3P PNP CLUB704/REF704A 4
Q20P 050303000054 IC TSD4905S TO-263 CLUB704/REF704A 1
Q8P, Q9P, Q10P,
050403000079 IC TSD3205S TO-263 CLUB704/REF704A 5
R122, R123, R222,
010803000013 RESISTOR DIP 0.15Ω 5W CLUB704/REF704A 8
RCA1 120203000085 RCA CONNECTOR CLUB704/REF704A 1
RTA, RTB, RTC,
080513000014 PTC 300~500Ω R80Ԩ ＞5KΩ CLUB704/REF704A 4
SW1 110103000061 SLIDE SWITCH 8P3T CLUB704/REF704A 1
SW1P 110603000028 TEMP. SWITCH 85Ԩ CLUB704/REF704A 1
SW2 110203000016 ROTARY SWITCH CLUB704/REF704A 1
SW2P 110603000021 TEMP. SWITCH JUC-31F CLUB704/REF704A 1
SW3, SW4 110103000062 BAND SWITCH 2P3T CLUB704/REF704A 2
T1 200403000218 TRASFO 14.4V H=23/Ф=38 CLUB704/REF704A 1
U1, U2, U3, U4, U5,
060103000654 IC NJM4580V SSOP8 CLUB704/REF704A 6
U1, U2, U3, U4, U5,
060103000654 IC NJM4580V SSOP8 CLUB704/REF704A 19
U1P 060103000383 IC TL494C SO-16 CLUB704/REF704A 1
U26 060103000469 IC HT7550 SOT-89 CLUB704/REF704A 1
U27 060103001603 IC SN8P2751P8AD SOP8 CLUB704/REF704A 1
U4P 050703000019 Photocoupler TLP185 SO8 CLUB704/REF704A 1
