12
Amplified, two-way, 15" with DSP
Molded polypropylene
129 dB Maximum SPL*
59 Hz - 16.5 kHz
49 Hz - 19 kHz
100° (horizontal) x 60° (vertical) nominal
300 WRMS (woofer) + 50 WRMS (driver)
15.0”
1.35”
2 x Combo (XLR/P10), 1 x P2, 1 x USB
100 kΩ
1 x XLR (active)
Streaming audio reception, Bluetooth version 5.0
Tone and Locate Functions
Predefined Independent Compressors and Limiters
110-127V or 220-240V selectable
400 WRMS
110-127V use: T6.3AL/250V
220-240V use: T3.15AL/250V
35 mm rod socket or lifting (3 points)
3 points with standard M10 thread
19 kg (41.9 lb)
729 x 425 x 415 mm (28.71 x 16.73 x 16.34 in.)
22,85 kg (50,37 lb)
795 x 495 x 515 mm (31,30 x 19,49 x 20,27 in.)
MAX 15 SPECIFICATIONS
TYPE OF SYSTEM:
STRUCTURE:
MAXIMUM SPL:
FREQUENCY RESPONSE (+3 dB):
FREQUENCY RESPONSE (+10 dB):
COVERAGE PATTERN:
RATED OUTPUT POWER:
WOOFER DIAMETER:
DRIVER DIAMETER:
INPUT CONNECTIONS:
INPUT IMPEDANCE:
OUTPUT CONNECTION:
BLUETOOTH:
DSP:
A.C. POWER SUPPLY:
MAXIMUM POWER CONSUMED:
FUSE:
MOUNTING:
LIFT POINTS:
NET WEIGHT:
DIMENSIONS (H x W x D);
GROSS WEIGHT:
PACKAGE DIMENSIONS (H x W x D):
* Measured at 2 meters distance with IEC standard pink noise,
±3 dB tolerance.
Bottom view Front view Side view Rear view
