Potential scrap of material
Process Step Material BOM number
Step18 Main board 993105180109
Step19 Cable tie 461031810019
Step21 LED board 993105180409
Step22-1 Battery 417200050109
Step22-2 EVA 420201320119
Step22-3 Seal glue 499020130009
Step23-1 3M glue paper 462700518069
Step23-2 High temperature tape 499010006029
Air leakage test membrane adhesive 462680518009
Air leakage test liquid 499041004099
10
Note:
1. pls make sure all the location where need to be fixed by screws must be evenly and tightly
2. After reassembly, try to press one passive radiator and observe the other one if it can stand up or take more than 10s to recover flat. If yes, it
should be OK if you have no special sealing equipments to test
3. Before testing the glue Should be held for 4 hours to wait for drying
To Next Page
